11356198 WEG AC Motors
Part#:11356198
Manufacturer:WEG
Product Lifecycle:Discontinued
Get a quick Quote!
W22 High Efficiency 300 HP 4P 447/9T 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted
Check out the 11356198 WEG price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 4
- Temperature rise 80 K
- Rotation¹ Both (CW and CCW)
- Frequency 60 Hz
- Locked rotor time 25s (cold) 14s (hot)
- Degree of Protection IP55
- Output rating 300 HP
- Frame 447/9T
- Insulation Class F
- Noise level² 75.0 dB(A)
- Rated torque 885 ft.lb
- Service factor 1.15
- Number of poles 4
- Rated speed 1780 rpm
- Breakdown torque 229 %
- Mounting F-1
- Flange Without
- Slip 1.11 %
- Moment of inertia (J) 105 sq.ft.lb
- Starting Method Direct On Line
- Synchronous speed 1800 rpm
- Rated current 270 A
- Design B
- Ambient temperature -20°C to +40°C
- Approx. weight³ 2425 lb
- Terminal box¹ Left position
- Rated voltage 575 V
- LRC 6.5x(Code G)
- Altitude 1000 m.a.s.l.
- Standard NEMA MG-1
- L. R. Amperes 1752 A
- No load current 84.0 A
- Duty Cycle Cont.(S1)
- Voltage 575 V
- Output 300 HP (220 kW)
- Locked rotor torque 229 %
- Enclosure IC411 - TEFC
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
