Q253E W/30 Banner Proximity Sensors
Part#:Q253E W/30
Manufacturer:Banner
Alt. Part#:33878
Product Lifecycle:Active
Get a quick Quote!
EZ-BEAM Q25 Series: Emitter; Range: 20 m; Input: 20-250 V ac; Output: Not Applicable; 9 m (30 ft) Cable
About the manufacturer: Banner is one of the manufacturers that offers Proximity Sensors that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the Q253E W/30 Banner price in the box on the right side or send a quick quote.
Product Details
- Weight580.59776 g
- Country Of OriginUS
- Primary Housing Material Thermoplastic
- Output response time (ms) 16 ON/8 OFF
- Barrel Diameter (mm) 18
- Sensing Beam Infrared LED
- Power Supply/Supply Voltage 20-250 V ac
- Delay at Power-up (ms) 100
- IO Link No
- Sensing Mode (General) Opposed
- Quick Disconnect Type No QD
- Number of Pins 2
- Feature: Washdown Rated Yes
- Cable Length (m) 9
- Operation N/A
- Special Feature: Water Detection No
- Max Op. Relative Humidity [%] 90% @ 50°C
- Sensing Mode (Detailed) Emitter
- Connection Cable
- Repeatability (µs) 2000
- Opposed Mode Emitter/Receiver Emitter
- DeviceNet No
- Outputs N/A
- Special Feature: Intrinsically Safe No
- Adjustments N/A
- Feature: Timing (Hold/Delay) No
- Max Sensing Distance (mm) 20000
- Special Feature: Remote Teach No
- Lens Material Polycarbonate
- Feature: Audible No
- Power AC
- Min Op. Temp. (°C) -40
- IP Rating IP69
- Feature: Ecolab Certified Yes
- Housing Style Rectangular
- Max Op. Temp. (°C) 70
- NEMA Rating NEMA 6P
- Feature: Chemical Resistant Yes
- Feature: Encapsulated Yes
- Feature: Hazardous Area No
- Indicator LEDs
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Q253E W/30 Description
Banner Engineering Q253E W/30 is a photo-electric sensor designed for through-beam system applications, functioning as an emitter alone. It features an M18 threaded mount for secure installation and is equipped with a pre-wired 30ft / 9m cable that terminates with bare end flying leads for easy connection. This sensor operates within an ambient air temperature range of -40 to +70°C and is suitable for use with supply voltages ranging from 20Vac to 250Vac, with nominal values at 200Vac, 220Vac, and 240Vac. Part of the Q25 AC series, it offers a high degree of protection rated at IP69K NEMA 6P, ensuring durability in demanding environments. The sensor's housing is made from thermoplastic with a polycarbonate lens, and it is designed in a rectangular shape. It has a sensing distance of 20m and utilizes infrared light with a wavelength of 950 nm. The response time of the sensor is 16ms / 0.016 s.
Related documents Q253E W/30 Specs
