DX80N9Q45VTP Banner Proximity Sensors
Part#:DX80N9Q45VTP
Manufacturer:Banner
Alt. Part#:806263
Product Lifecycle:Active
Get a quick Quote!
Wireless Q45 Vibration and Temperature Node; With 1-Wire Serial Interface 900 MHz 1 W; Pre-Configured Dip Switch Settings for VT1; Vibration and Temperature Sensor Sold Separately
About the manufacturer: Banner is one of the manufacturers that offers Proximity Sensors that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the DX80N9Q45VTP Banner price in the box on the right side or send a quick quote.
Product Details
- Weight294.8348 g
- Country Of OriginUS
- Power Supply 2 AA Batteries
- Point-to-Point Topology Yes
- PROFINET No
- Power Battery
- Tree Topology No
- Modbus/TCP No
- Environmental Rating (IP) IP67
- Feature: Hazardous Area No
- RS-485 No
- Environmental Rating (NEMA) NEMA 6P
- Relative Humidity 90% at 50° C
- RS-232 No
- Input/Output Serial
- Point-to-Multipoint Topology Yes
- EtherNet/IP No
- Housing Style Integrated Battery
- Application: Temperature Input Yes
- Wireless Radio Frequency 900 MHz
- Min Temp Operating Conditions -40
- Device Type Node
- Modbus RTU No
- Ships With Battery Yes
- Wireless Yes
- Max Temp Operating Conditions 70
- Star Topology Yes
- Application: Vibration Sensor Input Yes
- 1-wire Serial Interface Yes
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
DX80N9Q45VTP Description
Banner Engineering DX80N9Q45VTP is a Remote Terminal Unit (RTU) designed with a moulded reinforced thermoplastic polyester housing, an o-ring sealed transparent polycarbonate cover, a moulded acrylic lens, and stainless steel hardware. It operates within an ambient air temperature range of -40 to +70°C and offers a degree of protection rated at IP67 NEMA 6P. This unit has dimensions of H110.4mm x W44.4mm x D62.7mm and features a rectangular shape. It is equipped with a red/green LED visual position indicator for radio status and supports a light color of red/green. The DX80N9Q45VTP operates on a 900 MHz transmission frequency and is part of the SureCross Q45 all-in-one series for predictive maintenance. It includes functions such as vibration and temperature node and a 1-wire serial interface, designed for QM30VT1 monitoring with FHSS (Frequency Hopping Spread Spectrum) technology. The supply voltage is 3.6Vdc from an internal battery, and the housing color is black. It operates on a 900MHz ISM band with 1W power and can achieve a maximum transmission distance of 3.2km at nominal emission power. The unit is mounted using an M30 thread.
Related documents DX80N9Q45VTP Specs
