CL50GRBAOS3PQ Banner Electronic Components
Part#:CL50GRBAOS3PQ
Manufacturer:Banner
Product Lifecycle:Active
Get a quick Quote!
Banner Engineering CL50GRBAOS3PQ is a beacon designed for surface or base pole mounting with an M30 or 1/2" NPSM thread. It features a polycarbonate diffused window and an ABS/polycarbonate housing and base, suitable for ambient air temperatures ranging from -20°C to +50°C. This beacon has a current consumption of 100mA and offers a degree of protection rated at IP67, NEMA 13, UL type 13. Its cylindrical shape incorporates 3 x digital inputs (18-30Vdc; PNP) for color control and 1 x digital input (18-30Vdc; PNP) for alarm input. The CL50GRBAOS3PQ functions as a sealed omni-directional audible column light, with a 1.6Hz pulsed sound and a 1-tier 3-color G/R/B color pattern LED illumination. It connects via a pre-equipped 5-pin M12 Euro-style QD connector and operates on a supply voltage of 18Vdc-30Vdc (24Vdc nom.). The beacon has a diameter of 50mm / 2" and features a black housing.
About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the CL50GRBAOS3PQ Banner price in the box on the right side or send a quick quote.
Product Details
- Power Source DC
- Color Option 1 Green
- Color 3 - Wavelength/Color Temp/Coordinates 475 nm
- Max Op. Temperature (°C) 50
- Feature: Hazardous Area No
- Primary Housing Material ABS/Polycarbonate
- Animation Option 1 Solid On
- Lumens Color 3 28.0
- Max Input Response Time (ms) 10
- Feature: Quick Disconnect Yes
- Mounting Thread M30 x 1.5
- Quick Disconnect Type M12 (Euro)
- Animation Option 3 Solid On
- Max Audible Intensity (db at 1m) 99
- Primary Window Material Polycarbonate Diffused
- Product Size (mm) 50
- Connection Integral QD
- Color 2 - Wavelength/Color Temp/Coordinates 625 nm
- Input Type PNP
- Max Current - Audible Alarm (mA) 45
- Indication Yes
- Animation Option 2 Solid On
- Supply Voltage 18-30 V dc
- Min Op. Temperature (°C) -20
- Feature: Chemical Resistant No
- Power DC
- Color Option 2 Red
- Max Current Color (mA) 100
- Primary Housing Color Black
- Multi-Color Device Single Color On
- Color Technology Standard LED
- Color 1 - Wavelength/Color Temp/Coordinates 525 nm
- Number of Input Pins/Conductors 5
- Max Op. Relative Humidity Non-Condensing (%) 95% @ 50°C
- Feature: Audible Yes
- Housing Style Base Mount - Tower
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Lumens Color 2 38.0
- Audible Alarm Type Pulsed
- Audible Operating Frequency (kHz) 2.1
- IO Link No
- Number of Colors / Segments 3
- Lumens Color 1 72.0
- Color Option 3 Blue
- NEMA Type and UL Type Rating NEMA and UL 13
- Environmental Rating IP67
- Wireless No
- Physical Dimensions (LxWxH or DxH mm) 50.0 x 182.2
- Pro-Editor Compatible (Discrete) No
- Modbus RTU No
