Variable Frequency Drives (VFD)

M701-07500440A10101AB100

NIDEC M701-07500440A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M701 series designed with a built-in brake transistor and a single Safe Torque Off (STO) feature, utilizing air cooling. It has dimensions of frame size 7, measuring H20" x W10.63" x D11.02" (H508mm x W270mm x D280mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 53A under normal duty and 44A under heavy-duty conditions. It requires a supply voltage of 500Vac-575Vac and is designed to function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20 NEMA 1 UL open degree of protection and is compatible with a 3-phase input network, supporting a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It features 2 analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 6 digital inputs (0-24Vdc), 4 digital outputs (0-24Vdc; source and 2A / 240Vac; source; relay contact type), and 3 analog inputs (1 x differential and 2 x single-ended; 0-20mA / 4-20mA / -10...+10Vdc; 11-bit conversion resolution). The rated active power is 45kW for normal duty and 30kW for heavy-duty, with rated power of 50HP under normal duty and 40HP under heavy-duty conditions.

Nidec

HVW701B028T2N01-I-B

WEG HVW701B028T2N01-I-B - STANDARD PANEL HVW701B028T2N01-I-B, HVAC Enclosed Drives (HVW)

WEG

M701-07600240A10101AB100

NIDEC M701-07600240A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M701 series designed with a built-in brake transistor and a single Safe Torque Off (STO) feature, utilizing air cooling. It has dimensions of frame size 7, measuring H20" x W10.63" x D11.02" (H508mm x W270mm x D280mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 30A under normal duty and 24A under heavy-duty conditions. It requires a supply voltage of 500Vac-690Vac (600Vac) and is designed to function within an ambient air temperature range of -20°C to +40°C. The device offers a degree of protection of IP20 NEMA 1 UL open and is compatible with a 3-phase input network, with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It features 2 x analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 6 x digital inputs (0-24Vdc), 4 x digital outputs (0-24Vdc; source and 2A / 240Vac; source; relay contact type), and 3 x analog inputs (1 x differential and 2 x single-ended; 0-20mA / 4-20mA / -10...+10Vdc; 11-bit conversion resolution). The rated active power is 22kW for normal duty and 18.5kW for heavy-duty, corresponding to 30HP and 25HP, respectively.

Nidec

M600-03400062A10101AB100

NIDEC M600-03400062A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M600 series designed with a built-in brake transistor and a single Safe Torque Off (STO) feature, utilizing air cooling. It has dimensions of frame size 3, measuring H14.37" x W3.27" x D7.87" (H365mm x W83mm x D200mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 7.7A under normal duty and 6.2A under heavy-duty conditions. It is designed for a supply voltage of 380Vac-480Vac (specifically 400Vac / 415Vac) and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20 NEMA 1 degree of protection and is compatible with a 3-phase input network, supporting a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. It features 2 x analog outputs, 3 x digital inputs, 3 x additional digital inputs, 3 x digital outputs, and 1 x digital output of a relay contact type, alongside 1 x analog input with differential and 2 x analog inputs with single-ended connections, all supporting a variety of signal types and resolutions. The rated active power is 3kW for normal duty and 2.2kW for heavy-duty, corresponding to 5HP and 3HP, respectively.

Nidec

CFW500A04P3S2NB20G2

DRIVE CFW500A04P3S2NB20G2

WEG

I55AE211B10V1100LS

Lenze I55AE211B10V1100LS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control with additional features including compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It incorporates a built-in RFI filter, standard I.O., and conformal coating, with dimensions of H250mm x W60mm x D130mm. This model supports PROFINET communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 6A for heavy-duty applications at 230-240Vac, and it is suitable for supply voltages of 230Vac / 240Vac. The mounting mode is versatile, allowing for control cabinet or surface/wall mounting. It operates within an ambient air temperature range, with a maximum of 45°C at a switching frequency of 2kHz or 4kHz, and 40°C at a switching frequency of 8kHz or 16kHz, featuring an IP20 degree of protection. The network type is single-phase / 1P, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs with flexible functionality, 1 x digital output, and 2 x analog inputs, all supporting various configurations. The rated active power is 1.1kW, and the rated power is 1-1/2HP for heavy-duty applications at 230-240Vac.

Lenze

CFW500C03P0T5DBN1

WEG CFW500C03P0T5DBN1 - DRIVE CFW500C03P0T5DBN1, CFW500/700 Drives

WEG

F600-04200250A10101AB653

NIDEC F600-04200250A10101AB653 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for a wide range of automation applications. It operates within an ambient air temperature range of -20°C to +40°C and offers a degree of protection rated at IP65. This model features a frame size 4, with dimensions of H15.4" x W4.9" x D7.9" (H391mm x W124mm x D200mm). It is equipped with 1 x analog output (0-10Vdc), 2 x digital outputs (240Vac; relay contact type), 1 x analog input (4-20mA / 0-10Vdc; single-ended), and 3 x digital inputs (24Vdc) plus an additional 3 x digital inputs (0-24Vdc; configurable). The F600 series drive includes a built-in brake transistor, an internal line choke, and utilizes air cooling for temperature management. It requires a supply voltage of 200Vac-240Vac (220Vac / 230Vac) with a network frequency of 60 Hz and supports Modbus RTU communication protocol. The rated current for normal duty is 25A, with a rated active power of 5.5kW and a rated power of 7.5HP / 7-1/2HP for normal duty operations. This device is designed for a 3-phase input (3P) network.

Nidec

M000-09201760DU0100AN100

NIDEC M000-09201760DU0100AN100 is a Variable Speed/Frequency Drive (VSD/VFD) from the M000 series, designed with a built-in DC to AC inverter featuring air cooling. It has dimensions of frame size 9D, measuring H28.11" x W12.2" x D11.4" (H714mm x W310mm x D290mm). This part is rated for a heavy-duty current of 176A and operates on a supply voltage of 200Vac-240Vac (220Vac / 230Vac), with a network frequency supply input of 50 Hz. It offers a degree of protection of IP20 NEMA 1. The rated active power ranges from 90kW to 250kW, and the rated power is between 125HP and 400HP for heavy-duty applications.

Nidec

UMI-0040EE-B1

UMI-0040EE-B1 Unitronics - Unitronics VFD - B1 Casing, 380-480V, 3 Phase, 4kW, 5HP, STO included

Unitronics

GA80U4007AWM

GA80U4007AWM Yaskawa - Variable frequency drive (VFD), 3 phase, 480 VAC, 7 A, Flange (Type 12 Backside), General Purpose GA800 Series

Yaskawa

ACS35503U12A54J404

MACHINERY DRIVE, 7.5 HP, 12.5 A, 480 VAC, Voltage Range: 380-480V, UL TYPE OPEN (IP20), Cabinet-mounted, Basic Panel, 3-Phase Input, 3-Phase Output, Frame: R3

ABB Control

I55AE315F10V11002S

Lenze I55AE315F10V11002S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter applications, DC-injection braking, brake management for brake control, and includes S-ramps for smooth acceleration and deceleration. It features a flying restart circuit, PID controller, built-in RFI filter, standard I.O., and conformal coating. The dimensions are H347mm x W204.5mm x D222mm. It supports CANopen communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current varies with duty and voltage: 38.4A (light-duty; 400Vac), 32.4A (light-duty; 480Vac), 32A (heavy-duty; 400Vac), and 27A (heavy-duty; 480Vac). It operates on a supply voltage of 400Vac / 480Vac and can be mounted in a control cabinet or on a surface/wall. The ambient air temperature for operation is up to 45°C (at a switching frequency of 2kHz or 4kHz) and up to 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. It is designed for a 3-phase network (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The drive includes 1 analog output, 5 digital inputs (with options for frequency or encoder input), 1 digital output, and 2 analog inputs (with options for voltage or current input). The rated active power is 18.5kW (light-duty; 400-480Vac) and 15kW (heavy-duty; 400-480Vac), with a rated power of 25HP (light-duty; 400-480Vac) and 20HP (heavy-duty; 400-480Vac).

Lenze

M701-06400350A10101AB100

NIDEC M701-06400350A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M701 series designed with a built-in brake transistor and a single Safe Torque Off (STO) feature, utilizing air cooling. It has dimensions of frame size 6, measuring H14.37" x W8.27" x D8.94" (H365mm x W210mm x D227mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 38A under normal duty and 35A under heavy-duty conditions. It is designed for a supply voltage of 380Vac-480Vac (400Vac / 415Vac) and can function in ambient air temperatures ranging from -20°C to +40°C. The device offers an IP20 NEMA 1 UL open degree of protection and is suitable for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It features 2 analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 6 digital inputs (0-24Vdc), 4 digital outputs (0-24Vdc; source and 2A / 240Vac; source; relay contact type), and 3 analog inputs (0-20mA / 4-20mA / -10...+10Vdc; differential and single-ended; 11-bit conversion resolution). The rated active power is 18.5kW under normal duty and 15kW under heavy-duty, with a rated power of 25HP for both conditions.

Nidec

M14150B

Lenze M14150B is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for general purpose applications. It features dimensions of H286mm x W200mm x D174mm and supports Modbus communication protocol. The device offers thermal overload protection and solid state motor overload protection. It operates with a rated current of 24A at 400Vac and 21A at 460Vac, and a supply voltage of 400Vac / 480Vac. Suitable for control cabinet or surface/wall mounting, it can function within an ambient air temperature range of -10 to +50 °C. The M14150B has a NEMA 1 degree of protection and is compatible with a 3-phase network, accepting an input frequency of 48-62 Hz and outputting 0-120 Hz. It includes 1 analog output proportional to speed, 1 analog output proportional to load, 4 digital inputs, 1 digital input for start, 1 digital input for stop, and 2 digital outputs (NPN; sinking). Additionally, it features 1 analog input (0-10Vdc) and 1 analog input (4-20mA). The rated active power is 11kW, and the rated power is 15HP for both 400Vac and 480Vac.

Lenze

GA80U4250AWM

GA80U4250AWM Yaskawa - Variable frequency drive (VFD), 3 phase, 480 VAC, 250 A, Flange (Type 12 Backside), General Purpose GA800 Series

Yaskawa

H300-08201800A10101AB103

NIDEC H300-08201800A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the H300 series designed with a built-in brake transistor, internal line choke, and air cooling. It features dimensions of frame size 8, measuring H31.6" x W12.2" x D11.4" (H803mm x W310mm x D290mm). This model supports Modbus RTU communication protocol and operates with a rated current of 180A under normal duty. It is designed for a supply voltage of 200Vac-240Vac (220Vac / 230Vac) and can function within an ambient air temperature range of -20°C to +40°C. The device offers an IP20, NEMA 1, UL type 1 degree of protection and is compatible with a 3-phase input network at a supply frequency of 60 Hz. It includes 2 analog outputs, 6 digital inputs (3 of which are configurable), and 2 digital outputs (relay contact type), alongside 2 analog inputs (1 for 4-20mA and 1 for 0-10Vdc). The rated active power is 45kW (normal duty), with a rated power of 60HP (normal duty).

Nidec

M702-07500550A10101AB100

NIDEC M702-07500550A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the M702 series designed with a built-in brake transistor and dual Safe Torque Off (STO) for air cooling. It features dimensions of frame size 7, measuring H20" x W10.63" x D11.02" (H508mm x W270mm x D280mm). This model supports multiple communication protocols including Ethernet, Ethernet/IP, Modbus TCP, and PROFINET RT. It operates with a rated current of 73A under normal duty and 55A under heavy-duty conditions, and it is designed for a supply voltage range of 500Vac-575Vac. The ambient air temperature for operation is specified from -20°C to +40°C. It offers a degree of protection rated at IP20 NEMA 1 UL open and is suitable for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. The device includes 2 x digital inputs (0-24Vdc, with terminal 8 configurable as a motor protection thermistor) and 3 x digital outputs (2 x 100mA / 0-24Vdc source and 1 x 2A / 240Vac source; relay contact type). Its rated active power is 55kW under normal duty and 37kW under heavy-duty, corresponding to a rated power of 60HP and 50HP, respectively.

Nidec

HS30-03400094A10101AB100

NIDEC HS30-03400094A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) from the HS30 series designed for high-speed applications with a rated frequency output of 0-3000Hz (open loop). It features a built-in brake transistor and dual Safe Torque Off (STO) with air cooling. The dimensions are frame size 3, measuring H8.9" x W3.5" x D6.3" (H226mm x W90mm x D160mm). This model supports multiple communication protocols including CANopen, DeviceNet, Ethernet/IP, Modbus RTU, Modbus TCP, PROFINET RT, and PROFIBUS DP. It operates with a rated current of 9.4A for both normal and heavy-duty applications and requires a supply voltage of 380Vac-480Vac (400Vac / 415Vac). The ambient air temperature for operation ranges from -20°C to +55°C, and it has a degree of protection of IP20 NEMA 1. The network is 3-phase input (3P) with a supply input frequency of 45-66 Hz and an output frequency of 0-3000 Hz. It includes 1 analog output, 5 digital inputs plus 1 additional digital input, 2 digital outputs, and 2 analog inputs with an 11-bit conversion resolution. The rated active power and power are 4kW and 5HP for both normal and heavy-duty operations.

Nidec

EDP11S005GN1210000

STANDARD PANEL EDP11S005GN1210000

WEG
