Variable Frequency Drives (VFD)

I55AE222D10V0100LS

Lenze I55AE222D10V0100LS is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionalities. It features a standard I.O. with conformal coating, dimensions of H250mm x W60mm x D130mm, and supports PROFINET communication protocol. The drive offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 9.6A for heavy-duty applications at 230-240Vac, with a supply voltage of 230Vac / 240Vac. Suitable for control cabinet or surface/wall mounting, it operates within an ambient air temperature range of up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with an IP20 degree of protection. The drive accommodates a single-phase or 3-phase network, with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs with flexible functionality, 1 x digital output, and 2 x analog inputs, supporting both voltage and current input/output configurations. The rated active power is 2.2kW, and the rated power is 3HP for heavy-duty applications at 230-240Vac.

Lenze

M000-09402000EU0100AB100

NIDEC M000-09402000EU0100AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter, part of the M000 series, designed with a built-in brake transistor and requires an external choke and air cooling for operation. It has dimensions of frame size 9E, measuring H39.7" x W12.2" x D11.4" (H1010mm x W310mm x D290mm). This model is rated for a heavy-duty current of 200A and operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac), with a network frequency supply input of 50 Hz. It offers a degree of protection of IP20 NEMA 1. The rated active power ranges from 90kW to 250kW for heavy-duty applications, equivalent to 125HP to 400HP.

Nidec

ESV751N06TXC

ESV751N06TXC Lenze Variable Frequency Drive (VFD) - The SMV 1.0 hp (0.75 kW) drive features a 480 / 600 VAC 3Ø input in a convection cooled NEMA 4X (IP65) indoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated line filter ideal

Lenze

M000-09601040AU0100AB100

NIDEC M000-09601040AU0100AB100 is a Variable Speed/Frequency Drive (VSD/VFD) from the M000 series designed with a built-in brake transistor, internal line choke, and air cooling. It features a frame size of 9A with dimensions of H41.3" x W12.2" x D11.4" (H1049mm x W310mm x D290mm). This model is rated for a heavy-duty current of 104A and operates on a supply voltage of 500Vac-690Vac (600Vac), with a network frequency supply input of 50 Hz. It offers a degree of protection of IP20 NEMA 1 and is capable of delivering rated active power between 90kW and 110kW (heavy-duty), equivalent to 125HP-150HP.

Nidec

HVW701E142T2N12-J-C

WEG HVW701E142T2N12-J-C - STANDARD PANEL HVW701E142T2N12-J-C, HVAC Enclosed Drives (HVW)

WEG

I55AE390F1AV11002S

Lenze I55AE390F1AV11002S is a variable speed/frequency drive (VSD/VFD) or inverter within the Drives sub-range, designed for compact inverter applications including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H685mm x W258mm x D304mm. The communication protocol supported is CANopen, with protection functions against overvoltage category, leakage current, earth fault resistance, and overtemperature of the motor. It has a rated current of 216A (light-duty; 400Vac), 187A (light-duty; 480Vac), 180A (heavy-duty; 400Vac), and 156A (heavy-duty; 480Vac), with a supply voltage of 400Vac / 480Vac. The mounting mode is suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation is max. 45°C (at a switching frequency of 2kHz or 4kHz) and max. 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. It operates on a 3-phase network (3P / 3AC), with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). It includes 1 x analog output, 5 x digital inputs with optional uses for two of them, 1 x digital output, and 2 x analog inputs with optional uses. The rated active power is 110kW (light-duty; 400-480Vac) and 90kW (heavy-duty; 400-480Vac), with a rated power of 150HP (light-duty; 400-480Vac) and 125HP (heavy-duty; 400-480Vac).

Lenze

ESV752N04TMD

ESV752N04TMD Lenze Variable Frequency Drive (VFD) - The SMV 10.0 hp (7.5 kW) drive features a 400 / 480 VAC 3Ø input with input disconnect in a fan cooled NEMA 4X (IP65) indoor enclosure. The SMVector NEMA 4X (IP65) offers exemplary performance even in harsh environments. These decentralized drives are suitable for wall mounting and are available in two enclosure materials suitable for either indoor or outdoor use. This drive is also available with an integral disconnect switch and integrated l

Lenze

HS71-05200250A10101AB100

NIDEC HS71-05200250A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the HS71 series designed for variable speed control with rated frequency outputs of 0-3000Hz in open loop and 0-1250Hz in closed loop applications. It features a built-in brake transistor and a single Safe Torque Off (STO) function suitable for high-speed applications, utilizing air cooling for temperature management. The dimensions are frame size 5, measuring H15.4" x W5.6" x D7.6" (H391mm x W143mm x D200mm). It supports RS-485 communication protocol and operates with a rated current of 30A under normal duty and 25A under heavy-duty conditions. The supply voltage required is AC 200Vac-240Vac (220Vac / 230Vac), and it can operate in ambient air temperatures ranging from -20°C to +40°C. This model has an IP20, NEMA 1, UL open degree of protection, and is designed for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency up to 3000 Hz. It includes 2 x analog outputs, 6 x digital inputs, 4 x digital outputs, and 3 x analog inputs with varying conversion resolutions. The rated active power is 7.5kW for normal duty and 5.5kW for heavy-duty, corresponding to 10HP and 7.5HP respectively.

Nidec

HVW701B031T4N01-X-C

WEG HVW701B031T4N01-X-C - STANDARD PANEL HVW701B031T4N01-X-C, HVAC Enclosed Drives (HVW)

WEG

C300-02400023A10101AB100

NIDEC C300-02400023A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C300 series designed with dual Safe Torque Off (STO) and air cooling. It operates on a supply voltage of 380Vac-480Vac, including 400Vac and 415Vac, within a frame size of 2 measuring H8.07" x W2.95" x D5.9" (H205mm x W75mm x D150mm). This model offers an IP20 NEMA 1 degree of protection and supports a rated current of 2.3A for both normal and heavy-duty operations. It utilizes the Modbus RTU communication protocol over a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation ranges from -20°C to +60°C. It features 1 analog output (10Vdc; source; single-ended), 5 digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 1 digital output (50mA / 0-24Vdc; source; PWM) plus 1 digital output (2A / 240Vac; source; relay contact type). The analog inputs include 1 x analog input (0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution) and 1 x analog input (0-10Vdc; single-ended; 11-bit conversion resolution). It is rated for an active power of 0.75kW and a power rating of 1HP for both normal and heavy-duty applications.

Nidec

CFW110045T2ON1Z

DRIVE CFW110045T2ON1Z

WEG

M15300B

Lenze M15300B is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for general purpose applications. It features dimensions of H324mm x W261mm x D210mm and supports Modbus communication protocol. The device offers thermal overload protection and solid state motor overload protection. It operates with a rated current of 32A at 460Vac / 575Vac and a supply voltage of 480Vac / 590Vac. The M15300B can be mounted in a control cabinet or on a surface/wall and is designed to operate in ambient air temperatures ranging from -10 to +50 °C. It has a NEMA 1 degree of protection and is suitable for a 3-phase network with an input frequency of 48-62 Hz and an output frequency of 0-120 Hz. The unit includes 1 analog output proportional to speed (frequency), 1 analog output proportional to load, 4 digital inputs, 1 digital input for start, 1 digital input for stop, and 2 digital outputs (NPN; sinking). Additionally, it features 1 analog input (0-10Vdc) and 1 analog input (4-20mA). The rated active power is 22kW, and the rated power is 30HP at 480Vac / 590Vac.

Lenze

C200-09402240E10101AB100

NIDEC C200-09402240E10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C200 series designed with an external line reactor air cooling system. It operates on a supply voltage of 380Vac-480Vac, including 400Vac and 415Vac, within a frame size of 9E measuring H42.09" x W12.21" x D11.42" (H1069mm x W310mm x D290mm). This model offers a degree of protection rated at IP20 NEMA 1 and supports a rated current of 266A for Normal duty and 224A for Heavy-duty applications. It utilizes the Modbus RTU communication protocol over a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation spans from -20°C to +60°C. It features 1 analog output (10Vdc; source; single-ended), 5 digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 1 digital output (50mA / 0-24Vdc; source; PWM) along with 1 digital output (2A / 240Vac; source; relay contact type). The analog inputs include 1 input for 0-20mA / 4-20mA / 0-10Vdc (single-ended; 11-bit conversion resolution) and another for 0-10Vdc (single-ended; 11-bit conversion resolution). This device is rated for an active power of 132kW under Normal duty and 110kW under Heavy-duty, equivalent to 200HP and 150HP respectively.

Nidec

QMP155A4R

NIDEC QMP155A4R is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 4 quadrant operation with air cooling. It operates within an ambient air temperature range of 0°C to +55 °C and has a rated current of 155A. This model supports a supply voltage range of 208Vac-480Vac, accommodating various inputs including 220Vac, 230Vac, 240Vac, 380Vac, 400Vac, and 415Vac. The device's dimensions are frame size 1B, measuring H22.6" x W13" x D9.9" (H578mm x W330mm x D251mm), and it has a degree of protection rated at IP00. It is compatible with a single-phase input network (2P) and uses the Modbus RTU communication protocol. The QMP155A4R features 3 x digital outputs (240mA / 0-24Vdc; source) and 2 x digital outputs (5A / 240Vac; source; relay contact type), along with 1 x analog input (-10Vdc...10Vdc; differential) and 2 x analog inputs (0-20mA / 4-20mA / -10Vdc...10Vdc; single-ended). It also includes 3 x digital inputs (0-24Vdc) and an additional 3 x digital inputs (0-24Vdc), with a rated active power of 56kW and rated power of 90HP. The device provides 2 x analog outputs (0-20mA / 4-20mA / -10Vdc...10Vdc; source; single-ended) with a 10-bit conversion resolution.

Nidec

ATV61HC16Y

Schneider Electric ATV61HC16Y is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 61 series designed for three-phase networks with a supply voltage range of 425-759Vac, including nominal voltages of 480Vac, 500Vac, 600Vac, and 690Vac. It features variable speed/frequency drive capabilities with U/F ratio adjustments (2 points / 5 points / energy saving), sensorless flux vector control (standard / energy saving), and vector control without speed feedback, capable of delivering 120% of the nominal motor torque. The design incorporates a built-in EMC filter (class C3), a built-in heatsink, and a coated version for enhanced chemical resistance. The ATV61HC16Y has dimensions of H1190mm x W340mm x D377mm, offers a degree of protection rated at IP20 UL type 1, and supports wall mounting. It is equipped with a rated current of 200A at 500Vac and 2.5kHz, 180A at 690Vac and 2.5kHz, with a maximum current of 240A for 60 seconds. Communication is facilitated through Modbus and CANopen protocols. The output network frequency ranges from 0.1-500 Hz. It includes 1 analog output (0-10Vdc / 0-20mA), 5 digital inputs (24Vdc; sink/source) plus 1 additional digital input programmable as discrete or PTC input and another for PWR safety, along with 2 digital outputs (1 C/O SPDT relay contact and 1 NO relay contact). Analog inputs comprise 1 input for -10...+10Vdc and another for 0-10Vdc / 0-20mA. Current consumption is specified as 182A at 500Vac, 158.9A at 600Vac, and 163A at 690Vac, with rated active power outputs of 160kW at 690Vac and 132kW at 500Vac.

Schneider Electric

HVW701C038T4N01-J-X

WEG HVW701C038T4N01-J-X - STANDARD PANEL HVW701C038T4N01-J-X, HVAC Enclosed Drives (HVW)

WEG

SP5201

NIDEC SP5201 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed with a single Safe Torque Off (STO) and air cooling. It features a frame size of 5, measuring H33.75" x W12.2" x D11.73" (H857mm x W310mm x D298mm), and operates on a supply voltage of 200Vac-240Vac (220Vac / 230Vac). The SP5201 is rated at 130A for normal duty and 105A for heavy-duty applications. It is designed for wall-mounted installations and can operate in ambient air temperatures ranging from 0°C to +40°C. This model offers an IP20 NEMA 1 degree of protection and supports Modbus RTU RS-485 communication protocol. The network frequency ranges from 48-65 Hz for supply input and 0-550 Hz for output. It includes 3 x digital outputs (0-24Vdc; source), 1 x digital output (2A / 240Vac; source; relay contact type), 3-phase input, 3 x digital inputs (0-24Vdc), and analog inputs/outputs with varying specifications. The rated active power is 37kW for normal duty and 30kW for heavy-duty, corresponding to 50HP and 40HP, respectively.

Nidec

I5DAE155F10V10000S

Lenze I5DAE155F10V10000S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Power units sub-range, designed with a built-in RFI filter. This inverter power unit does not feature a communication interface but is equipped with protection functions including overvoltage category, leakage current, earth fault resistance, and overtemperature of the motor. It supports a rated current of 1.8A for heavy-duty applications at 400Vac and 1.6A at 480Vac, with a supply voltage of 400Vac / 480Vac. The I5DAE155F10V10000S is suitable for control cabinet or surface/wall mounting, offering a degree of protection rated at IP20. It operates on a 3-phase (3P / 3AC) network, with a rated active power of 0.55kW and a rated power of 3/4HP for heavy-duty applications within the 400-480Vac range.

Lenze

I55AE255C10V01003S

Lenze I55AE255C10V01003S is a variable speed/frequency drive (VSD/VFD) and compact inverter designed for precise control of motor speed and torque. Part of the Drives sub-range, it features DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, a flying restart circuit, and a PID controller. The design includes a standard I.O. with conformal coating, measuring H250mm x W90mm x D130mm. It supports Modbus RTU communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. The rated current is 27.6A for light-duty (230-240Vac) and 23A for heavy-duty (230-240Vac) applications. It operates on a supply voltage of 230Vac / 240Vac and can be mounted in a control cabinet or on a surface/wall. The ambient air temperature for operation varies with the switching frequency, allowing a maximum of 45°C at 2kHz or 4kHz and 40°C at 8kHz or 16kHz. It has an IP20 degree of protection, is designed for a 3-phase network (3P / 3AC), and operates with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The unit includes 1 analog output (0-10Vdc; 0-20mA or 4-20mA), 5 digital inputs (PNP/NPN logic), 1 digital output (max. 100mA), and 2 analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 7.5kW for light-duty and 5.5kW for heavy-duty applications, with a rated power of 10HP and 7-1/2HP, respectively.

Lenze

I55AE311F10V11001S

Lenze I55AE311F10V11001S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed and frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionalities. It features a built-in RFI filter, application I.O. conformal coating, but lacks a communication interface. The protection functions include overvoltage category, leakage current, earth fault resistance, and overtemperature of motor protection. It supports a rated current of 28.2A for light-duty at 400Vac, 25.2A for light-duty at 480Vac, 23.5A for heavy-duty at 400Vac, and 21A for heavy-duty at 480Vac. The supply voltage is 400Vac / 480Vac, suitable for control cabinet or surface/wall mounting. The operational ambient air temperature ranges up to 45°C at a switching frequency of 2kHz or 4kHz, and up to 40°C at 8kHz or 16kHz, with a degree of protection of IP20. It operates on a 3-phase network (3P / 3AC) with a network frequency of 45-65 Hz (input) and 0-599 Hz (output). The device includes 2 x analog outputs, 7 x digital inputs with specific functionalities for some, 2 x digital outputs, and 2 x analog inputs, all supporting various configurations. The rated active power is 15kW for light-duty and 11kW for heavy-duty, both at 400Vac / 480Vac, translating to a rated power of 20HP for light-duty and 15HP for heavy-duty, at the same voltages.

Lenze
