Variable Frequency Drives (VFD)

C200-02400023A10101AB100

NIDEC C200-02400023A10101AB100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the C200 series designed with air cooling. It operates on a supply voltage of 380Vac-480Vac (400Vac / 415Vac) and has dimensions of frame size 2 H8.07" x W2.95" x D5.9" (H205mm x W75mm x D150mm). This model offers a degree of protection of IP20 NEMA 1 and is rated for a current of 2.3A for both normal and heavy-duty operations. It supports Modbus RTU communication protocol and is designed for a 3-phase input network with a supply input frequency of 45-66 Hz and an output frequency range of 0-550 Hz. The ambient air temperature for operation ranges from -20°C to +60°C. It features 1 x analog output (10Vdc; source; single-ended), 5 x digital inputs (0-24Vdc; PNP/NPN) plus 1 additional digital input (0-24Vdc), and 1 x digital output (50mA / 0-24Vdc; source; PWM) plus 1 digital output (2A / 240Vac; source; relay contact type). The analog inputs include 1 x analog input (0-20mA / 4-20mA / 0-10Vdc; single-ended; 11-bit conversion resolution) and 1 x analog input (0-10Vdc; single-ended; 11-bit conversion resolution). It is rated at 0.75kW (1HP) for both normal and heavy-duty applications.

Nidec

I55AE318F1AV11002S

Lenze I55AE318F1AV11002S is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter within the Drives sub-range, designed for variable speed/frequency control, compact inverter DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and PID controller functionality. It features a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and dimensions of H347mm x W204.5mm x D222mm. The communication protocol supported is CANopen, with protection functions including overvoltage category, leakage current, earth fault resistance, and overtemperature of motor. It has a rated current of 48A (light-duty; 400Vac), 40.8A (light-duty; 480Vac), 40A (heavy-duty; 400Vac), and 34A (heavy-duty; 480Vac), with a supply voltage of 400Vac / 480Vac. The mounting mode is suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation is max. 45°C (at a switching frequency of 2kHz or 4kHz) and max. 40°C (at a switching frequency of 8kHz or 16kHz), with a degree of protection of IP20. It operates on a 3-phase (3P / 3AC) network, with a network frequency of (input) 45-65 Hz and (output) 0-599 Hz. It includes 1 x analog output (0-10Vdc; 0-20mA or 4-20mA), 5 x digital inputs (PNP/NPN logic), 1 x digital output (max. 100mA), and 2 x analog inputs (-10...+10Vdc; 0-20mA or 4-20mA). The rated active power is 22kW (light-duty; 400-480Vac) and 18.5kW (heavy-duty; 400-480Vac), with a rated power of 30HP (light-duty; 400-480Vac) and 25HP (heavy-duty; 400-480Vac).

Lenze

EDP11S038GN1201000

STANDARD PANEL EDP11S038GN1201000

WEG

ATV71HU22Y

Schneider Electric ATV71HU22Y is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the Altivar 71 series, designed for variable speed and frequency control with a U/F ratio of 2 points / 5 points and sensorless flux vector control. It features ENA System Vector control with or without speed feedback, delivering 220% of the nominal motor torque for 2 seconds and 170% of the nominal motor torque for 60 seconds. This model comes with a built-in EMC filter, built-in heatsink, and a coated version for enhanced durability. It operates on a supply voltage of 425-759Vac, with specific nominal voltages at 480Vac, 500Vac, 600Vac, and 690Vac. The dimensions are H420mm x W240mm x D236mm, and it has a conformal coating for chemical resistance. The degree of protection includes IP20, IP21, and UL type 1. The rated current varies with voltage: 3.2A at 500Vac, 2.7A at 575Vac, and 4A at 690Vac, with a maximum current of 5.28A for 2 seconds and 4.8A for 60 seconds. For installation, it supports wall mounting and communicates via Modbus and CANopen protocols. It is designed for a 3-phase network with an output frequency range of 0.1-599 Hz. The device includes 1 analog output, 5+1 programmable digital inputs, 3 digital outputs, and 2 analog inputs. The current consumption is specified for different voltages, and the rated active power is 2.2kW at 690Vac and 1.5kW at 500Vac, equivalent to 2HP.

Schneider Electric

H300-06500170A10101AB653

NIDEC H300-06500170A10101AB653 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter from the H300 series designed with a built-in brake transistor, internal line choke, and air cooling. It features dimensions of frame size 6, measuring H15.4" x W8.3" x D8.9" (H391mm x W210mm x D227mm). This model supports Modbus RTU communication protocol and operates with a rated current of 17A under normal duty conditions. It is designed for a supply voltage range of 500Vac-575Vac and can function within an ambient air temperature range of -20°C to +40°C. The device offers a degree of protection rated at IP65, NEMA 4, UL type 12, and is suitable for 3-phase input networks with a supply input frequency of 60 Hz. It includes 2 analog outputs, 6 digital inputs (3 of which are configurable), and 1 digital input (0-24Vdc), alongside 2 digital outputs (relay contact type), and 2 analog inputs (1 for 4-20mA and 1 for 0-10Vdc). The rated active power is 11kW under normal duty, equivalent to 15HP.

Nidec

CFW500A01P6T4NB20G2

DRIVE CFW500A01P6T4NB20G2

WEG

GA80U4031AWM

GA80U4031AWM Yaskawa - Variable frequency drive (VFD), 3 phase, 480 VAC, 31 A, Flange (Type 12 Backside), General Purpose GA800 Series

Yaskawa

F600-03400123A10101AB103

NIDEC F600-03400123A10101AB103 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 3-phase input with a supply voltage range of 380Vac-480Vac, specifically 400Vac / 415Vac, and operates on a 60 Hz network frequency. It features a built-in brake transistor, internal line choke, and air cooling design, ensuring optimal performance within an ambient air temperature range of -20°C to +40°C. This model, part of the F600 series, offers a rated current of 12.3A under normal duty conditions, with a rated active power of 5.5kW and a rated power of 7.5HP / 7-1/2HP. It is equipped with 1 analog input (4-20mA / 0-10Vdc; single-ended), 1 analog output (0-10Vdc), 3 digital inputs (24Vdc and 0-24Vdc; configurable), and 2 digital outputs (240Vac; relay contact type), supporting Modbus RTU communication protocol. The device is housed in a frame size 3, measuring H15" x W3.3" x D7.9" (H382mm x W83mm x D200mm), and is protected by an IP20 enclosure.

Nidec

HVW701C058T4N01-J-A

WEG HVW701C058T4N01-J-A - STANDARD PANEL HVW701C058T4N01-J-A, HVAC Enclosed Drives (HVW)

WEG

CFW500D47P0T2DB20G2

DRIVE CFW500D47P0T2DB20G2

WEG

CFW110024T4O55DSZ

DRIVE CFW110024T4O55DSZ

WEG

HVW701B017T4N01-I-B

WEG HVW701B017T4N01-I-B - STANDARD PANEL HVW701B017T4N01-I-B, HVAC Enclosed Drives (HVW)

WEG

EDP11S013DN3R11000

STANDARD PANEL EDP11S013DN3R11000

WEG

M701-11502540E10101AN100

NIDEC M701-11502540E10101AN100 is a Variable Speed/Frequency Drive (VSD/VFD) from the M701 series designed for variable speed control with a single Safe Torque Off (STO) and requires an external choke for air cooling. It features dimensions of frame size 11E, measuring H46.9" x W12.2" x D48.9" (H1190mm x W310mm x D312mm). This model supports RS-485 Modbus RTU communication protocol and operates with a rated current of 288A under normal duty and 254A under heavy-duty conditions. It is designed for a supply voltage range of 500Vac-575Vac and can operate in ambient air temperatures ranging from -20°C to +40°C. The drive offers an IP20 NEMA 1 UL open degree of protection and is suitable for 3-phase input networks with a supply input frequency of 45-66 Hz and an output frequency range of 0-599 Hz. It includes 2 analog outputs (0-20mA / 4-20mA / -10...+10Vdc; source; 10-bit conversion resolution), 6 digital inputs (0-24Vdc), 4 digital outputs (0-24Vdc; source and 2A / 240Vac; source; relay contact type), and 3 analog inputs (0-20mA / 4-20mA / -10...+10Vdc; with different conversion resolutions). The rated active power is 225kW under normal duty and 185kW under heavy-duty, corresponding to 300HP and 250HP, respectively.

Nidec

CFW700A05P0T4DB20

DRIVE CFW700A05P0T4DB20

WEG

F600-05500039A10101AB653

NIDEC F600-05500039A10101AB653 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter designed for 3-phase input with a supply voltage range of 500Vac-575Vac and a network frequency of 60 Hz. It features a built-in brake transistor, an internal line choke, and air cooling for efficient operation. The device offers a rated current of 3.9A and rated active power of 2.2kW, equivalent to 3HP under normal duty conditions. It is equipped with 1 analog input (4-20mA / 0-10Vdc; single-ended), 1 analog output (0-10Vdc), 3 digital inputs (24Vdc), and 3 additional digital inputs (0-24Vdc; configurable), alongside 2 digital outputs (240Vac; relay contact type). The F600 series inverter operates within an ambient air temperature range of -20°C to +40°C and is protected by an IP65-rated enclosure, ensuring its components are shielded from dust and water ingress. Its dimensions are frame size 5, measuring H15.4" x W5.6" x D7.6" (H391mm x W143mm x D200mm). Communication is facilitated via the Modbus RTU protocol, allowing for integration into various industrial networks.

Nidec

CFW500B02P6T4DBN1

WEG CFW500B02P6T4DBN1 - DRIVE CFW500B02P6T4DBN1, CFW500/700 Drives

WEG

CFW110024T2ON1Z-PGS

DRIVE CFW110024T2ON1Z-PGS

WEG

I55AE125B1AV11003S

Lenze I55AE125B1AV11003S is a Variable Speed/Frequency Drive (VSD/VFD) from the Drives sub-range, designed for compact inverter applications with features including DC-injection braking, brake management for brake control, S-ramps for smooth acceleration and deceleration, flying restart circuit, and a PID controller. It incorporates a built-in RFI filter, safe torque off (STO) safety standard, I.O. conformal coating, and has dimensions of H155mm x W60mm x D130mm. This model supports Modbus RTU communication protocol and offers protection functions against overvoltage, leakage current, earth fault resistance, and overtemperature of the motor. It operates with a rated current of 1.7A for heavy-duty applications at 230-240Vac, and is suitable for control cabinet or surface/wall mounting. The ambient air temperature for operation varies with the switching frequency, allowing a maximum of 45°C at 2kHz or 4kHz and 40°C at 8kHz or 16kHz. It has an IP20 degree of protection, is designed for single-phase / 1P networks with an input frequency of 45-65 Hz and an output frequency of 0-599 Hz. The drive features 1 analog output, 5 digital inputs with flexible functionality, 1 digital output, and 2 analog inputs, all supporting various configurations. It is rated for an active power of 0.25kW and a power capacity of 1/3HP for heavy-duty applications at 230-240Vac.

Lenze

M000-10601780EU0100AN100

NIDEC M000-10601780EU0100AN100 is a Variable Speed/Frequency Drive (VSD/VFD) / Inverter, part of the M000 series, designed for heavy-duty applications. It requires an external choke and utilizes air cooling. The dimensions are frame size 10E, measuring H39.7" x W12.2" x D11.4" (H1010mm x W310mm x D290mm). This model has a rated current of 178A and operates on a supply voltage of 500Vac-690Vac (600Vac), with a network frequency of 50 Hz. It offers a degree of protection of IP20 NEMA 1. The rated active power ranges from 90kW to 250kW, and the rated power is between 125HP and 400HP for heavy-duty operations.

Nidec
