AC/DC Power Supplies

ML30.102

PULS ML30.102 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and features a NEC Class 2 design for very low output noise. The unit provides a rated current of 2.5A at 12Vdc and utilizes spring-clamp connections for connectivity. It supports a wide supply voltage range from 85Vac to 264Vac (with specific nominal values across 100Vac to 240Vac at 47-63Hz, including a 46Vac turn-ON voltage and a 44Vac shutdown voltage) and from 88Vdc to 375Vdc (with nominal values including 100Vdc to 250Vdc). The ML30.102 is housed in a PC / ABS blend and is suitable for single-phase (1AC) or DC networks. It measures 45mm in width, 75mm in height, and 91mm in depth. The rated power is 30W, and the output voltage is adjustable between 10-12Vdc, with a 250mV turn-ON overshoot. It includes protection functions such as NTC for input inrush current limiting. The efficiency is rated at 0.84 with a 230Vac input, and it has a current consumption of 17A max. inrush at 120Vac input and 35A peak max. inrush at 230Vac input. Power dissipation/losses are calculated at 5.8W, and the ripple is specified at 10mVpp over a frequency range of 20Hz to 20MHz at 50Ω.

Puls

HRP-150-24

AC-DC Single output enclosed power supply; Output 24Vdc at 6.5A; 1U low profile; free air convection

MEAN WELL

LPS-100-27

AC-DC Single output Open frame power supply; Output 27Vdc at 3.8A

MEAN WELL

HRP-600-48

AC-DC Single output enclosed power supply; Output 48Vdc at 13A; fan cooling

MEAN WELL

IRM-10-15

AC-DC Single output Encapsulated power supply; Input 85-264Vac; Output 15Vdc at 0.67A; PCB mount; miniature size

MEAN WELL

TDR-480-48

AC-DC Industrial 3-phase DIN rail power supply with PFC and Constant Current; Output 48VDc at 10A

MEAN WELL

EDR-75-48

AC-DC Industrial DIN rail power supply; Output 48V at 1.6A; metal case

MEAN WELL

RSP-500-5

AC-DC Single Output Enclosed power supply; Output 5VDC Single Output at 90A; PFC; forced air cooling; 1U low profile

MEAN WELL

EPS-65-36

AC-DC Single output Open frame power supply; Output 36Vdc at 1.81A

MEAN WELL

WDR-480-48

AC-DC Industrial DIN rail power supply; Output 48Vdc at 10A; metal case; Ultra wide input 180-550Vac for single and two phase mains network

MEAN WELL

MDR-100-12

AC-DC Industrial DIN rail power supply; Output 12Vdc at 7.5A; plastic case

MEAN WELL

MDR-60-12

AC-DC Industrial DIN rail power supply; Output 12Vdc at 5A; plastic case

MEAN WELL

MDR-20-12

AC-DC Industrial DIN rail power supply; Output 12Vdc at 1.67A; plastic case

MEAN WELL

HRPG-600-24

AC-DC Single output enclosed power supply; Output 24Vdc at 27A; fan cooling; remote on/off + 5Vdc at 0.3A standby

MEAN WELL

IRM-30-12

AC-DC Single output Encapsulated power supply; PCB mount; Input 85-264VAC; Output 12VDC at 2.5A; Compact size

MEAN WELL

RSP-2400-12

AC-DC Single Output Enclosed power supply; Output 12VDC Single Output at 166A; PFC; forced air cooling

MEAN WELL

QS3.241

PULS QS3.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 3.4A at 24Vdc and 3A at 28Vdc, with spring-clamp connections for ease of installation. It supports a supply voltage range of 85Vac-264Vac for AC and 88Vdc-375Vdc for DC, accommodating various network configurations including single-phase (1AC) or DC. The QS3.241, part of the Q-series, measures 32mm in width, 124mm in height, and 102mm in depth, housed in an aluminium casing. It delivers a rated power of 80W at 24V, 84W at 28V, and can handle up to 120W short-term for 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, with comprehensive protection functions against overvoltage, overload, and short-circuit conditions. Efficiency rates vary by input voltage, achieving up to 0.9 at 230Vac. The unit exhibits a start-up delay of 330-360ms, with a hold time of 174ms at 230Vac input. Power dissipation is noted at 9.1W for 230Vac input under full load. Electrical durability spans up to 224000 hours, depending on conditions, and the output stage capacitance is 1500µF, with a ripple of 50mVpp across a 20Hz to 20MHz range.

Puls

UHP-750-24

AC-DC Slim Single output enclosed power supply with PFC; Output 24Vdc at 31.3A; DC OK signal

MEAN WELL

UHP-500-48

AC-DC Slim Single output enclosed power supply with PFC; Output 48VDC at 10.45A

MEAN WELL

NDR-120-12

AC-DC Single output Industrial DIN rail power supply; Output 12Vdc at 10A; metal case

MEAN WELL
