AC/DC Power Supplies

CP20.241-R2

PULS CP20.241-R2 is a DIN rail mounting power supply unit housed in an aluminium casing, designed for a wide range of industrial applications. It operates within an ambient air temperature range of -40 to +70°C and offers a net width of 48mm. The unit consumes current differently based on the input voltage: 2.25A at 230Vac, 4.28A at 120Vac, 5.17A at 100Vac input for full output, and 4.64A at 110Vdc input for a 24Vdc / 10A output, with peak inrush currents of 5.5A at 230Vac and 12A at 120Vac. It boasts an efficiency of 0.952 at 230Vac input and 0.938 at 120Vac input. The dimensions are W48mm x H124mm x D127mm. The power supply features a 450ms start-up delay and a rise time of 145ms to 160ms under nominal input conditions. It includes protection functions such as output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. The unit is resistant to back-feeding loads up to 35V. Power dissipation losses are 24.2W at 230Vac input and 31.7W at 120Vac input, with an output stage capacitance of 8000µF. Electrical durability ranges from 25,000 to 465,000 hours depending on the operating conditions. The ripple is specified at 100mVpp. This AC/DC power supply unit is part of the CP-series and is designed with built-in decoupling MOSFET for redundancy, hot-swappable connectors, and ATEX approval. It offers a 20% power reserve and features a DC-OK relay contact output. The connection type is hot-swappable connectors. Supply voltage ranges from 88Vdc to 180Vdc for DC and 85Vac to 264Vac for AC, with specific tolerances for overvoltage and shutdown voltages. The rated current is 24A at 48Vdc in temperatures up to +45°C, with derating at higher temperatures. It supports single-phase (1AC) or DC networks and provides a rated power of 576W at temperatures up to +45°C, with linear derating up to +70°C. The output voltage is fixed at 24Vdc, with a 1000mV turn-ON overshoot and a hold time of 32ms at 120/230Vac input.

Puls

CP20.241-R1

PULS CP20.241-R1 is a DIN rail mounting power supply unit housed in an aluminium casing, designed to operate within an ambient air temperature range of -40 to +70°C. It features a net width of 48 mm and offers a degree of protection rated at IP20. This unit consumes current at rates of 2.25A with a 230Vac input, 4.28A with a 120Vac input, 5.17A with a 100Vac input, and 4.64A with a 110Vdc input for a 24Vdc / 10A output, with peak inrush currents of 5.5A at 230Vac input and 12A at 120Vac input. It boasts an efficiency of 0.952 at 230Vac input and 0.938 at 120Vac input. The dimensions of this power supply are W48mm x H124mm x D127mm. It has a 450ms start-up delay for 100-230Vac input, with rise times of 145ms and 160ms under specified conditions. The CP20.241-R1 includes protection functions such as output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation for increased output voltages or power. It is resistant to back-feeding loads up to 35V. Power dissipation losses are 24.2 W and 31.7 W for 230Vac and 120Vac inputs respectively, with an output stage capacitance of 8000 µF. Electrical durability ranges from 25,000 to 465,000 hours under various conditions. The ripple is specified at 100mVpp. This AC/DC power supply unit, part of the CP-series, is designed with built-in decoupling MOSFET for redundancy, ATEX approval, and features a 20% power reserve, DC-OK relay contact output, and spring-clamp connections. It supports a supply voltage range of 88Vdc-180Vdc and 85Vac-264Vac, with specific tolerances for overvoltage and shutdown voltages. The rated current is 24A at 48Vdc in temperatures up to +45°C, with derating at higher temperatures. It is suitable for single-phase (1AC) or DC networks, providing a rated power of 576W at temperatures up to +45°C, and features a fixed 24Vdc output voltage with a 1000mV turn-ON overshoot and a hold time of 32ms.

Puls

QS5.241-A1

PULS QS5.241-A1 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and boasts ATEX approval, conformal coating, and a DC-OK relay contact output for enhanced functionality. The unit provides a rated current of 5A at 24Vdc and 4.5A at 28Vdc, with spring-clamp connections facilitating secure and reliable connectivity. It supports a wide supply voltage range from 85Vac to 264Vac for AC inputs and 88Vdc to 360Vdc for DC inputs, ensuring versatility across different power networks. The QS5.241-A1, part of the Q-series, measures 40mm in width, 124mm in height, and 117mm in depth, housed in a durable aluminium casing. It delivers a rated power of 120W at 24V and 126W at 28V, with a short-term capacity of 180W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, and the unit includes comprehensive protection functions against overvoltage, overload, and short circuits. It is designed for single-phase or DC networks and demonstrates high efficiency rates up to 0.927, depending on the input voltage. The QS5.241-A1 also features a peak inrush current of 15A, a start-up delay between 85 to 120ms, and a hold time of up to 65ms, depending on the input voltage. Power dissipation is minimized to 9.4W at full output load with a 230Vac input. Its electrical durability is rated up to 252,000 hours at optimal conditions, with a ripple of 50mVpp and an output stage capacitance of 3500µF, ensuring stable and reliable operation over its lifespan.

Puls

CP10.241-M1

PULS CP10.241-M1 is a DIN rail mounting power supply unit with an aluminium housing, designed for a net width of 39 mm. It operates within an ambient air temperature range of -25 to +70°C and features a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. The efficiency rates are 0.952 at 230Vac input, 0.936 at 120Vac input, and 0.929 at 100Vac input. Its dimensions are W39mm x H124mm x D117mm. The unit has a start-up delay of 240-300ms for 100-230Vac input, with a rise time of 30ms under nominal input at constant full current load with 0mF load capacitance, and 75ms with 10mF load capacitance. It includes protection functions such as output overvoltage protection and overload/short-circuit current protection, with specific resistance to back-feeding loads up to 35V. Power dissipation/losses are 12.1 W at 230Vac input with full output load and 16.4 W at 120Vac input with full output load. The output stage capacitance is 4400 µF. Electrical durability varies with conditions, reaching up to 499000 hours at 25°C with 5A output and 1AC 230Vac input. The ripple is 50mVpp (20Hz...20MHz; 50Ω). This AC/DC power supply unit, part of the CP-series designed for medical applications, features a DC-OK relay contact output and spring-clamp connections. It supports a supply voltage range of 85Vac-264Vac for various nominal inputs and 264-300Vac input overvoltage for up to 500ms. The rated current is 10A at 24Vdc with a derating from 6W/+60°C to +70°C. It is suitable for single-phase networks, offers a rated power of 240W, and provides an adjustable output voltage of 24Vdc-28Vdc with a 200mV turn-ON overshoot. The hold time is 37ms.

Puls

QS5.241

PULS QS5.241 is a power supply unit designed for AC/DC conversion with a 50% power reserve, suitable for DIN rail mounting. It operates within an ambient air temperature range of -25 to +70°C and features a DC-OK relay contact output for enhanced monitoring. The unit provides a rated current of 5A at 24Vdc and 4.5A at 28Vdc, with spring-clamp connections facilitating secure and reliable connectivity. It supports a wide supply voltage range from 85Vac to 264Vac across various nominal values and from 88Vdc to 360Vdc, ensuring flexibility across different power networks. The QS5.241, part of the Q-series, is housed in an aluminium casing, measuring 40mm in width, 124mm in height, and 117mm in depth. It delivers a rated power of 120W at 24V and 126W at 28V, with a short-term capacity of 180W for up to 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, with comprehensive protection functions including output overvoltage protection and overload/short-circuit protection. It allows for series or parallel operation to increase output power and is designed to handle back-feeding loads without malfunctioning. The unit boasts high efficiency rates up to 0.927 depending on the input voltage and has a peak current consumption of 15A. It features a start-up delay of 85-120ms, with a rise time of 18ms to 38ms depending on load capacitance, and a hold time of 34ms to 65ms. Power dissipation is minimized, and the unit demonstrates exceptional electrical durability, with operational lifespans ranging up to 252000 hours under optimal conditions. The output stage capacitance is 3500µF, and ripple is maintained at 50mVpp, ensuring stable power delivery.

Puls

CS5.241-C1

PULS CS5.241-C1 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers various current consumption rates depending on the input voltage: 1.23A at 230Vac, 2A at 120Vac, and 2.33A at 100Vac, with a peak inrush current of 10A across all input voltages. The unit boasts an efficiency of 0.902 at 230Vac, 0.894 at 120Vac, and 0.888 at 100Vac. Its printed circuit board is conformal coated, enhancing its resistance to harsh environments. The dimensions are W32mm x H124mm x D117mm. It features a start-up delay of 740-900ms and rise times of 8ms and 25ms under different load capacitances. Protection functions include output overvoltage protection, active input inrush current limiter, and overload/short-circuit current protection, with capabilities for series/parallel operation for redundancy. The unit can handle back-feeding loads up to 35V without malfunctioning. Power dissipation/losses are 13.2W and 14.5W for 230Vac and 120Vac inputs, respectively, at full output load. The output stage capacitance is 1800µF. Electrical durability varies with conditions, reaching up to 408000 hours at 25°C and 2.5A output with a 230Vac input. The ripple is maintained at 50mVpp. This AC/DC power supply unit, part of the C-Line series, includes a 20% power reserve, DC-OK relay contact output, and screw-clamp connections. It supports a supply voltage range of 85Vac-132Vac / 184Vac-264Vac with auto-selection and features rated currents of 6A and 5A at 24Vdc under different ambient temperatures, with a rated power of 144W at less than 45°C ambient temperature. The output voltage is adjustable between 24Vdc and 28Vdc, with a hold time of 78ms and 80ms at 230Vac and 120Vac inputs, respectively.

Puls

CPS20.361

PULS CPS20.361 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It operates within an ambient air temperature range of -25 to +70°C and offers a net width of 65mm. This unit has a current consumption of 2.33A at 230Vac input for full 36Vdc output, 4.36A at 120Vac input, and 5.25A at 100Vac input, with a peak inrush current of 13A at both 230Vac and 120Vac inputs. It features an IP20 degree of protection and boasts efficiencies of 0.943, 0.93, and 0.924 at 230Vac, 120Vac, and 100Vac inputs respectively. The dimensions of the CPS20.361 are W65mm x H124mm x D127mm. It includes a 900ms start-up delay and offers rise times of 90ms and 200ms under specified conditions. The unit is equipped with protection functions including output overvoltage protection and overload/short-circuit protection, and it supports series/parallel operation for increased output power. The power dissipation/losses are rated at 29W, and the output stage capacitance is 3800µF. Its electrical durability varies based on conditions, with up to 516000 hours at 25°C and 6.7A output with 1AC 230Vac input. The ripple is specified at 100mVpp. This AC/DC power supply unit features a 20% power reserve, is part of the C-series, and has ATEX approval. Connection is facilitated through screw-clamp connections, and it accepts a supply voltage range of 85Vac-264Vac. The rated current is 13.3A at 36Vdc, suitable for single-phase networks, with a rated power of 576W under PowerBoost at ambient temperatures less than 45°C and 480W at less than 60°C. The output voltage is adjustable between 36Vdc and 42Vdc, with a 1V turn-ON overshoot, and it offers a hold time of 26ms.

Puls

CP10.361

PULS CP10.361 is a DIN rail mounting power supply unit with an aluminium housing designed for a wide range of industrial applications. It features a net width of 39 mm and operates within an ambient air temperature range of -25 to +70°C. The unit has a current consumption of 11A peak max. inrush at 230Vac input and 7A peak max. inrush at 120Vac input. Its efficiency rates are 0.954 at 230Vac input, 0.938 at 120Vac input, and 0.931 at 100Vac input. The dimensions of the CP10.361 are W39mm x H124mm x D117mm. It includes a time delay of 240-300ms for start-up and a rise time of 60ms under nominal input with a constant full current load without load capacitance, and 120ms with 7mF load capacitance. The unit is equipped with protection functions including output overvoltage protection and overload/short-circuit protection, with the capability for series or parallel operation for increased output voltages or power. It can handle back-feeding loads up to 50V without malfunctioning. Power dissipation/losses are 11.6W at full output load with 230Vac input and 15.9W with 120Vac input. The output stage capacitance is 1500µF. Electrical durability varies with conditions, reaching up to 553000 hours at 25°C with 3.35A output and 1AC 230Vac input. The ripple is 50mVpp across a 20Hz to 20MHz range. This AC/DC power supply unit offers a 20% power reserve and includes ATEX approval, DC-OK relay contact output, and screw-clamp connections. It supports a supply voltage range of 88Vdc-180Vdc and 85Vac-264Vac, with a rated current of 6.7A at 36Vdc, and provides an adjustable output voltage of 36Vdc-42Vdc. The hold time is 38ms at both 120/230Vac input.

Puls

AP486.112

19" Rack Power Supply, 130W

Puls

QS40.484

PULS QS40.484 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 20A at 48Vdc and 17.8A at 54Vdc, with a power derating applicable from 24W at +60°C to +70°C. Connection is facilitated through screw-clamp connections, and it supports a supply voltage range of 180Vac to 264Vac, accommodating various nominal voltages within this range at a frequency of 47-63Hz. The QS40.484, part of the Q-series, measures 125mm in width, 124mm in height, and 127mm in depth, housed in an aluminium casing. It is designed for single-phase network operation and delivers a rated power of 960W, with a short-term capacity of 1440W for up to 4 seconds. The output voltage is adjustable between 48Vdc and 54Vdc. Protection features include output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation to increase output power. Efficiency is rated at 0.95 with a 230Vac input, and the unit exhibits a peak current consumption of 18A. Start-up and rise times are specified as 750ms and 18-35ms respectively, with a hold time of 30ms at 230Vac input. Power dissipation losses are detailed for both 230Vac and 120Vac inputs, and the electrical durability spans from 65,000 to 345,000 hours under various conditions. Ripple is maintained at 150mVpp across a 20Hz to 20MHz range, with an output stage capacitance of 3700µF.

Puls

QS40.481

PULS QS40.481 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and is equipped with ATEX approval, a DC-OK relay contact output, and screw-clamp connections. This unit supports a supply voltage range of 85Vac-264Vac across various nominal voltages and frequencies, with specific turn-ON and shutdown voltages. It belongs to the Q-series and is housed in an aluminium casing with dimensions of W125mm x H124mm x D127mm. The QS40.481 is designed for single-phase networks, offering a rated current of 20A at 48Vdc and 17.8A at 54Vdc, with a derating power of 24W at temperatures ranging from +60°C to +70°C. Its rated power is 960W, with a short-term capacity of 1440W for up to 4 seconds, and an adjustable output voltage between 48Vdc and 54Vdc. Protection features include output overvoltage protection and overload/short-circuit protection, with capabilities for series or parallel operation to increase output power. The unit demonstrates high efficiency rates across various input voltages and has specific inrush current, time delay, hold time, power dissipation/losses, and electrical durability metrics. It also features a ripple of 150mVpp and an output stage capacitance of 3700µF.

Puls

QS40.361

PULS QS40.361 is a power supply unit designed for AC/DC conversion with a 50% power reserve. It features DIN rail mounting and operates within an ambient air temperature range of -25 to +70°C. This unit is ATEX approved and includes a DC-OK relay contact output. It provides a rated current of 26.7A at 36Vdc and 22.9A at 42Vdc, with screw-clamp connections for installation. The supply voltage ranges from 85Vac to 264Vac across various nominal voltages, with specific turn-ON and shutdown voltages. Part of the Q-series, it measures 125mm in width, 124mm in height, and 127mm in depth, housed in aluminium. Designed for single-phase networks, it offers a rated power of 960W, extendable to 1440W for short-term applications, and an adjustable output voltage between 36Vdc and 42Vdc. Protection features include output overvoltage protection and active input inrush current limiting, with capabilities for overload, short-circuit protection, and series/parallel operation. Efficiency rates vary with input voltage, and it has specific current consumption, time delay, hold time, power dissipation, and electrical durability metrics. The ripple is 130mVpp, and the output stage capacitance is 4700µF.

Puls

ML30.102

PULS ML30.102 is a power supply unit (PSU) / converter designed for AC/DC applications with DIN rail mounting. It operates within an ambient air temperature range of -10 to +70°C and features a NEC Class 2 design for very low output noise. The unit provides a rated current of 2.5A at 12Vdc and utilizes spring-clamp connections for connectivity. It supports a wide supply voltage range from 85Vac to 264Vac (with specific nominal values across 100Vac to 240Vac at 47-63Hz, including a 46Vac turn-ON voltage and a 44Vac shutdown voltage) and from 88Vdc to 375Vdc (with nominal values including 100Vdc to 250Vdc). The ML30.102 is housed in a PC / ABS blend and is suitable for single-phase (1AC) or DC networks. It measures 45mm in width, 75mm in height, and 91mm in depth. The rated power is 30W, and the output voltage is adjustable between 10-12Vdc, with a 250mV turn-ON overshoot. It includes protection functions such as NTC for input inrush current limiting. The efficiency is rated at 0.84 with a 230Vac input, and it has a current consumption of 17A max. inrush at 120Vac input and 35A peak max. inrush at 230Vac input. Power dissipation/losses are calculated at 5.8W, and the ripple is specified at 10mVpp over a frequency range of 20Hz to 20MHz at 50Ω.

Puls

EPS-65-36

AC-DC Single output Open frame power supply; Output 36Vdc at 1.81A

MEAN WELL

MDR-100-12

AC-DC Industrial DIN rail power supply; Output 12Vdc at 7.5A; plastic case

MEAN WELL

MDR-60-12

AC-DC Industrial DIN rail power supply; Output 12Vdc at 5A; plastic case

MEAN WELL

MDR-20-12

AC-DC Industrial DIN rail power supply; Output 12Vdc at 1.67A; plastic case

MEAN WELL

IRM-30-12

AC-DC Single output Encapsulated power supply; PCB mount; Input 85-264VAC; Output 12VDC at 2.5A; Compact size

MEAN WELL

QS3.241

PULS QS3.241 is a power supply unit designed for DIN rail mounting, featuring AC/DC conversion with a 50% power reserve. It operates within an ambient air temperature range of -25 to +70°C and offers a design that includes a DC-OK relay contact output. The unit provides a rated current of 3.4A at 24Vdc and 3A at 28Vdc, with spring-clamp connections for ease of installation. It supports a supply voltage range of 85Vac-264Vac for AC and 88Vdc-375Vdc for DC, accommodating various network configurations including single-phase (1AC) or DC. The QS3.241, part of the Q-series, measures 32mm in width, 124mm in height, and 102mm in depth, housed in an aluminium casing. It delivers a rated power of 80W at 24V, 84W at 28V, and can handle up to 120W short-term for 4 seconds. The output voltage is adjustable between 24Vdc and 28Vdc, with comprehensive protection functions against overvoltage, overload, and short-circuit conditions. Efficiency rates vary by input voltage, achieving up to 0.9 at 230Vac. The unit exhibits a start-up delay of 330-360ms, with a hold time of 174ms at 230Vac input. Power dissipation is noted at 9.1W for 230Vac input under full load. Electrical durability spans up to 224000 hours, depending on conditions, and the output stage capacitance is 1500µF, with a ripple of 50mVpp across a 20Hz to 20MHz range.

Puls

NDR-120-12

AC-DC Single output Industrial DIN rail power supply; Output 12Vdc at 10A; metal case

MEAN WELL
