12541471 WEG AC Motors
Part#:12541471
Manufacturer:WEG
Product Lifecycle:Discontinued
Get a quick Quote!
W22 Tru-Metric IE2 25 HP 8P 225S/M 3Ph 460//380-415 V 60 Hz IC411 - TEFC - B3L(E)
Check out the 12541471 WEG price in the box on the right side or send a quick quote.
Product Details
- LRC 6.3
- Duty Cycle S1
- Noise level² 56.0 dB(A)
- Output 25 HP (18.5 kW)
- Rated torque 180 ft.lb
- Altitude 1000 m.a.s.l.
- Synchronous speed 900 rpm
- Frame 225S/M
- Locked rotor time 30s (cold) 17s (hot)
- Enclosure IC411 - TEFC
- Output rating 25 HP
- Rated speed 730 rpm
- Breakdown torque 210 %
- Mounting B3L(E)
- Slip 2.67 %
- Locked rotor torque 170 %
- Degree of Protection IP55
- Number of poles 8
- Number of Poles 8
- Moment of inertia (J) 19.8 sq.ft.lb
- Standard NEMA MG-1
- Flange Without
- Rated current 36.7 A
- Insulation Class F
- Voltage 460//380-415 V
- Frequency 50 Hz
- No load current 15.0 A
- Ambient temperature -20°C to +40°C
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Right position
- L. R. Amperes 231 A
- Design N
- Approx. weight³ 798 lb
- Rated voltage 380 V
- Temperature rise 80 K
- Starting Method Direct On Line
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
