11143251 WEG AC Motors
Part#:11143251
Manufacturer:WEG
Product Lifecycle:Discontinued
Get a quick Quote!
Close Coupled Pump High Efficiency 25 HP 2P 256JP 3Ph 230/460 V 60 Hz IC01 - ODP - Footless
Check out the 11143251 WEG price in the box on the right side or send a quick quote.
Product Details
- Frame 256JP
- Breakdown torque 250 %
- Duty Cycle Cont.(S1)
- Output rating 25 HP
- Rated speed 3530 rpm
- Temperature rise 105 K
- Rotation¹ Both (CW and CCW)
- Number of poles 2
- Rated torque 37.2 ft.lb
- Degree of Protection IP23
- Approx. weight³ 234 lb
- Rated current 58.6/29.3 A
- Design B
- Noise level² 67.0 dB(A)
- Output 25 HP (18.5 kW)
- LRC 6.0x(Code G)
- Moment of inertia (J) 0.9774 sq.ft.lb
- Voltage 230/460 V
- Flange C
- Frequency 60 Hz
- Service factor 1.15
- Mounting W-6
- Rated voltage 230/460 V
- Insulation Class F
- Altitude 1000 m.a.s.l.
- Synchronous speed 3600 rpm
- Number of Poles 2
- No load current 18.8/9.40 A
- Enclosure IC01 - ODP
- Slip 1.94 %
- Locked rotor torque 200 %
- Starting Method Direct On Line
- Terminal box¹ Left position
- L. R. Amperes 352/176 A
- Locked rotor time 18s (cold) 10s (hot)
- Ambient temperature -20°C to +40°C
- Standard NEMA MG-1
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
