10018OT3E404JM WEG AC Motors
Part#:10018OT3E404JM
Manufacturer:WEG
Alt. Part#:7891327712201
Product Lifecycle:Active
Get a quick Quote!
Close Coupled Pump NEMA Premium Efficiency 100 HP 4P 404/5JM 3Ph 230/460 V 60 Hz IC01 - ODP - Foot-mounted
Check out the 10018OT3E404JM WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating100 HP
- Rated Speed1780 rpm
- Number of Poles4 Pole
- Voltage230/460 V
- Flange TypeC
- LRC 6.7x(Code G)
- Temperature rise 80 K
- Voltage 230/460 V
- Rated voltage 230/460 V
- Design B
- Starting Method Direct On Line
- Number of poles 4
- L. R. Amperes 1514/757 A
- Breakdown torque 270 %
- Altitude 1000 m.a.s.l.
- Output rating 100 HP
- Frequency 60 Hz
- Insulation Class F
- Standard NEMA MG-1
- Number of Poles 4
- Duty Cycle Cont.(S1)
- Approx. weight³ 988 lb
- Slip 1.11 %
- No load current 84.0/42.0 A
- Service factor 1.15
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- Rated speed 1780 rpm
- Moment of inertia (J) 22.8 sq.ft.lb
- Mounting F-1
- Noise level² 69.0 dB(A)
- Rated current 226/113 A
- Rated torque 295 ft.lb
- Enclosure IC01 - ODP
- Flange C
- Output 100 HP (75 kW)
- Locked rotor torque 229 %
- Ambient temperature -20°C to +40°C
- Synchronous speed 1800 rpm
- Frame 404/5JM
- Locked rotor time 18s (cold) 10s (hot)
- Degree of Protection IP23
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents 10018OT3E404JM Specs
1-year warranty
