07518OT3V365JPV-W40 WEG AC Motors
Part#:07518OT3V365JPV-W40
Manufacturer:WEG
Alt. Part#:7909492966203
Product Lifecycle:Active
Get a quick Quote!
W40 JP Pump NEMA Premium Efficiency 75 HP 4P 364/5JP 3Ph 200/400 V 60 Hz IC01 - ODP - Footless
Check out the 07518OT3V365JPV-W40 WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating75 HP
- Rated Speed1780 rpm
- Number of Poles4 Pole
- Voltage200/400 V
- Flange TypeC
- Output 75 HP (55 kW)
- Rated current 197/98.3 A
- Locked rotor torque 220 %
- Ambient temperature -20°C to +40°C
- Enclosure IC01 - ODP
- Number of Poles 4
- LRC 6.8x(Code G)
- Service factor 1.25
- Starting Method Direct On Line
- Frame 364/5JP
- Temperature rise 80 K
- Standard NEMA MG-1
- L. R. Amperes 1337/669 A
- Locked rotor time 25s (cold) 14s (hot)
- Degree of Protection IP23
- Voltage 200/400 V
- Moment of inertia (J) 16.8 sq.ft.lb
- Approx. weight³ 780 lb
- Frequency 60 Hz
- Breakdown torque 260 %
- Altitude 1000 m.a.s.l.
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Left position
- Rated voltage 200/400 V
- Noise level² 69.0 dB(A)
- Slip 1.11 %
- Design B
- Synchronous speed 1800 rpm
- Rated speed 1780 rpm
- Rated torque 221 ft.lb
- Insulation Class F
- Mounting W-6
- Number of poles 4
- Flange C
- No load current 70.2/35.1 A
- Duty Cycle Cont.(S1)
- Output rating 75 HP
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents 07518OT3V365JPV-W40 Specs
