00236OS3E56CFL-S WEG AC Motors
Part#:00236OS3E56CFL-S
Manufacturer:WEG
Alt. Part#:7909158534340
Product Lifecycle:Active
Get a quick Quote!
Rolled Steel Standard Efficiency 2 HP 2P 56C 3Ph 230/460//190-220/380-415 V 60 Hz IC01 - ODP - Footless
Check out the 00236OS3E56CFL-S WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating2 HP
- Rated Speed3470 rpm
- Number of Poles2 Pole
- Voltage230/460 V
- Flange TypeC
- Output 2 HP (1.5 kW)
- Rated torque 3.03 ft.lb
- Temperature rise 80 K
- Synchronous speed 3600 rpm
- Slip 3.61 %
- Design A
- Altitude 1000 m.a.s.l.
- Number of poles 2
- Frame 56C
- Moment of inertia (J) 0.0840 sq.ft.lb
- Service factor 1.15 (1.00 @ 208V)
- Standard NEMA MG-1
- Rated speed 3470 rpm
- Locked rotor torque 229 %
- Noise level² 62.0 dB(A)
- Breakdown torque 250 %
- Ambient temperature -20°C to +40°C
- Number of Poles 2
- Insulation Class F
- Approx. weight³ 25.7 lb
- Rated voltage 230/460 V
- Starting Method Direct On Line
- Rotation¹ Both (CW and CCW)
- Voltage 230/460//190-220/380-415 V
- Frequency 60 Hz
- Locked rotor time 18s (cold) 10s (hot)
- Duty Cycle Cont.(S1)
- Output rating 2 HP
- Rated current 5.64/2.82 A
- LRC 7.0x(Code J)
- Mounting F-1
- Terminal box¹ Without Terminal Box
- L. R. Amperes 39.5/19.7 A
- No load current 2.60/1.30 A
- Enclosure IC01 - ODP
- Flange C
