LC1K0610U7 Schneider Electric Industrial Automation Components
Part#:LC1K0610U7
Manufacturer:Schneider Electric
Product Lifecycle:Active
Get a quick Quote!
Schneider Electric LC1K0610U7 is a magnetic contactor within the K sub-range, featuring screw connections and equipped with 3 poles (3P; 3NO). It has a rated current of 20A for AC-1 and 6A for 440Vac in AC-3 conditions. The contactor's net width is 45 mm and it offers a degree of protection rated at IP20. The control voltage (AC) ranges from 192-276Vac (230/240Vac nominal; 50Hz/60Hz; 0.8...1.15 x Uc). Its rated operating voltage (Ue) reaches up to 690 V, and it includes 1 Normally Open (NO) auxiliary contact. The rated impulse voltage (Uimp) is 8 kV, and the rated active power (kW) varies from 1.5kW at 220-230Vac to 3kW at 660-690Vac in AC-3 conditions. This model does not have Normally Closed (NC) auxiliary contacts. Its mechanical durability at no load is rated for 10,000,000 operations, and the rated voltage (AC) phase-to-phase stands at 690 V.
About the manufacturer: Schneider Electric is one of the manufacturers that offers Industrial Automation Components that you can order at marketplace.quotebeam.com. We provide digital solutions for energy and automation that improve efficiency and support sustainability. Our comprehensive solutions include cutting-edge energy technologies, real-time automation, software, and services for residential, commercial, and industrial settings.
Check out the LC1K0610U7 Schneider Electric price in the box on the right side or send a quick quote.
Product Details
- Heat Dissipation 1.3 W
- Range TeSys
- Signalling Circuit Frequency <= 400 Hz
- Height 2.28 in (58 mm)
- Device Short Name LC1K
- Auxiliary Contact Composition 1 NO
- Inrush Power In VA 30 VA 68 °F (20 °C))
- Product Or Component Type Contactor
- Contactor Application Motor control
- [Ie] Rated Operational Current 6 A<= 440 V AC AC-3 power circuit
- Mechanical Durability 10 Mcycles
- Device Application Control
- Hold-In Power Consumption In VA 4.5 VA 68 °F (20 °C))
- Depth 2.24 in (57 mm)
- [Uc] Control Circuit Voltage 230...240 V AC 50/60 Hz
- Maximum Operating Rate 3600 cyc/h
- Electrical Durability 1.3 Mcycles 6 A AC-3 <= 440 V
- Poles Description 3P
- Overvoltage Category III
- Insulation Resistance > 10 MOhm for signalling circuit
- Minimum Switching Voltage 17 V signalling circuit
- Width 1.77 in (45 mm)
- Product Name TeSys K
- [Uimp] Rated Impulse Withstand Voltage 8 kV
- Average Impedance 3 mOhm - Ith 20 A 50 Hz power circuit
- Power Pole Contact Composition 3 NO
- Minimum Switching Current 5 mA signalling circuit
- Net Weight 0.40 lb(US) (0.18 kg)
- Control Circuit Type AC at 50/60 Hz
- Auxiliary Contacts Type Instantaneous 1 NO
- Non Overlap Distance 0.02 in (0.5 mm)
- Utilisation Category AC-4 AC-3
- Safety Reliability Level B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1 B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1
- Mounting Support Rail Plate
- [Ith] Conventional Free Air Thermal Current 20 A 122 °F (50 °C) power circuit 10 A 122 °F (50 °C) signalling circuit
- Tightening Torque 11.51 lbf.in (1.3 N.m) screw clamp terminals Philips No 2 11.51 lbf.in (1.3 N.m) screw clamp terminals flat Ø 6 mm
- [Ue] Rated Operational Voltage Power circuit 690 V AC 50/60 Hz Signalling circuit <= 690 V AC 50/60 Hz
- Control Circuit Voltage Limits Operational: 0.8...1.15 Uc (at <50 °C) Drop-out: 0.2...0.75 Uc (at <50 °C)
- Operating Time 10...20 ms coil de-energisation and NO opening 10...20 ms coil energisation and NO closing
- Irms Rated Making Capacity 110 A AC power circuit NF C 63-110 110 A AC power circuit IEC 60947 110 A AC signalling circuit IEC 60947
- Associated Fuse Rating 25 A gG <= 440 V power circuit 25 A aM power circuit 10 A gG signalling circuit IEC 60947 10 A gG signalling circuit VDE 0660
- Connections - Terminals screw clamp terminals 1 0.00…0.01 in² (1.5…4 mm²)solid screw clamp terminals 1 0.00…0.01 in² (0.75…4 mm²)flexible without cable end screw clamp terminals 1 0.00…0.00 in² (0.34…2.5 mm²)flexible with cable end screw clamp terminals 2 0.00…
- Mechanical Robustness Shocks contactor closed, on X axis: 10 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor closed, on Y axis: 15 Gn for 11 ms conforming to IEC 60068-2-27 Shocks contactor closed, on Z axis15 Gn for 11 ms IEC 60068-2-27 Shocks contac
- [Icw] Rated Short-Time Withstand Current 90 A 122 °F (50 °C) - 1 s power circuit 85 A 122 °F (50 °C) - 5 s power circuit 80 A 122 °F (50 °C) - 10 s power circuit 60 A 122 °F (50 °C) - 30 s power circuit 45 A 122 °F (50 °C) - 1 min power circuit 40 A 122 °F (50 °C) - 3 mi
- Rated Breaking Capacity 110 A 415 V IEC 60947 110 A 440 V IEC 60947 80 A 500 V IEC 60947 110 A 220...230 V IEC 60947 110 A 380...400 V IEC 60947 70 A 660...690 V IEC 60947
- [Ui] Rated Insulation Voltage Power circuit 600 V UL 508 Power circuit 690 V IEC 60947-4-1 Signalling circuit 690 V IEC 60947-4-1 Signalling circuit 690 V IEC 60947-5-1 Signalling circuit 600 V UL 508 Power circuit 600 V CSA C22.2 No 14 Signalling circuit
- Motor Power Kw 1.5 kW 220...230 V AC 50/60 Hz AC-3 2.2 kW 380...415 V AC 50/60 Hz AC-3 3 kW 440 V AC 50/60 Hz AC-3 3 kW 480 V AC 50/60 Hz AC-3 3 kW 500...600 V AC 50/60 Hz AC-3 3 kW 660...690 V AC 50/60 Hz AC-3 1.5 kW 400 V AC 50/60 Hz AC-4
