MAE616Q Banner Measurement Sensors
Part#:MAE616Q
Manufacturer:Banner
Alt. Part#:72190
Product Lifecycle:Active
Get a quick Quote!
MAE616Q 16CH 2-STICK MA EMITTER
About the manufacturer: Banner is one of the manufacturers that offers Measurement Sensors that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the MAE616Q Banner price in the box on the right side or send a quick quote.
Product Details
- Weight716.67536 g
- Country Of OriginMX
- Main function Sensor (Edge)
- Sub-range name MINI-ARRAY 2-piece models
- Resolution 3/4" / 19mm
- Product series / family name A-GAGE series
- Connection type Pre-wired with 6" / 150mm PVC pigtal terminated with M12 Mini-style connector
- Degree of protection IP65 UL type 1
- Ambient air temperature for operation -40...+70 °C
- Primary brand Banner Engineering
- Supply voltage (DC) 16Vdc-30Vdc (24Vdc nom.)
- Dimensions 143mm array length
- Order code / Manufacturer SKU 72190
- Distance 3/4" / 19mm beam spacing/pitch
- Detectable object size 25.4-38.1mm
- Functions Measuring light screen array emitter red LED (status)
- Material Aluminium housing PVC connector
- Modbus RTU No
- Array Length (mm) 143
- Power DC
- RS-232 No
- Minimum Object Sensitivity (mm) 25.4-38.1
- Primary Housing Material Aluminum
- Housing Length (mm) 231
- Min Temp (°C) -40
- Beam Spacing 19 mm
- Discrete Output N/A
- Sensing Mode (Detailed) Emitter
- Analog Output N/A
- Emitter/Receiver Range (m) 0.9 - 16.5
- DeviceNet No
- Number of Beams 8
- Max Relative Humidity 95%
- IO Link No
- Max Temp (°C) 70
- Device Type Two-Piece
- RS-485 No
- Power Supply 16-30V dc
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
MAE616Q Description
Banner Engineering MAE616Q is a sensor from the MINI-ARRAY 2-piece models series designed for measuring light screen array functions, specifically as an emitter alone. This part features a 143mm array length in a rectangular shape with an aluminium housing and a PVC connector. It has a 3/4" / 19mm beam spacing/pitch and comes pre-wired with a 6" / 150mm PVC pigtail terminated with an M12 mini-style connector. The MAE616Q operates on a supply voltage of 16Vdc-30Vdc, with 24Vdc nominal, and can function within an ambient air temperature range of -40 to +70°C. It offers a degree of protection rated at IP65 UL type 1 and is capable of sensing distances from 90cm to 16.5m. With a resolution of 3/4" / 19mm, it can detect object sizes between 25.4mm and 38.1mm.
Related documents MAE616Q Specs
