MAE6016Q Banner Measurement Sensors
Part#:MAE6016Q
Manufacturer:Banner
Alt. Part#:72505
Product Lifecycle:Active
Get a quick Quote!
MAE6016Q 16CH 2-STICK MA EMITTER
About the manufacturer: Banner is one of the manufacturers that offers Measurement Sensors that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the MAE6016Q Banner price in the box on the right side or send a quick quote.
Product Details
- Weight2812.2704 g
- Country Of OriginMX
- Primary brand Banner Engineering
- Supply voltage (DC) 16Vdc-30Vdc (24Vdc nom.)
- Ambient air temperature for operation -40...+70 °C
- Sub-range name MINI-ARRAY 2-piece models
- Dimensions 1514mm array length
- Order code / Manufacturer SKU 72505
- Distance 3/4" / 19mm beam spacing/pitch
- Resolution 3/4" / 19mm
- Detectable object size 25.4-38.1mm
- Product series / family name A-GAGE series
- Main function Sensor (Edge)
- Connection type Pre-wired with 6" / 150mm PVC pigtal terminated with M12 Mini-style connector
- Degree of protection IP65 UL type 1
- Functions Measuring light screen array emitter red LED (status)
- Material Aluminium housing
- RS-232 No
- Array Length (mm) 1514
- Sensing Mode (Detailed) Emitter
- Minimum Object Sensitivity (mm) 25.4-38.1
- Beam Spacing 19 mm
- RS-485 No
- Emitter/Receiver Range (m) 0.9 - 13.5
- IO Link No
- Min Temp (°C) -40
- Primary Housing Material Aluminum
- Analog Output N/A
- Max Temp (°C) 70
- Power DC
- Modbus RTU No
- Discrete Output N/A
- Device Type Two-Piece
- Number of Beams 80
- Max Relative Humidity 95%
- DeviceNet No
- Housing Length (mm) 1603
- Power Supply 16-30V dc
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
MAE6016Q Description
Banner Engineering MAE6016Q is a sensor from the MINI-ARRAY 2-piece models series designed for measuring light screen array functions, specifically as an emitter alone. It features a 1514mm array length within a rectangular, aluminium housing. This model has a beam spacing/pitch of 3/4" / 19mm and comes pre-wired with a 6" / 150mm PVC pigtail terminated with an M12 mini-style connector. It operates on a supply voltage range of 16Vdc to 30Vdc, with 24Vdc as the nominal voltage. The MAE6016Q can function within an ambient air temperature range of -40 to +70°C and offers a degree of protection rated at IP65 UL type 1. Its sensing distance spans from 90cm to 13.5m, with a resolution of 3/4" / 19mm, and it can detect objects sized between 25.4mm and 38.1mm.
