DXM150-S2R2 Banner I/O Modules
Part#:DXM150-S2R2
Manufacturer:Banner
Alt. Part#:800845
Product Lifecycle:Active
Get a quick Quote!
DXM150 Modbus Slave Device; Multihop Radio 900 MHz 1 W; Inputs: 2 Discrete, 8 Universal; Outputs: 8 Discrete, 2 Analog; RS485
About the manufacturer: Banner is one of the manufacturers that offers I/O Modules that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the DXM150-S2R2 Banner price in the box on the right side or send a quick quote.
Product Details
- Weight566.99 g
- Country Of OriginUS
- Device Type Modbus Slave Device
- Min Temp Operating Conditions -40
- Modbus RTU Yes
- Analog Inputs Yes
- Housing Style External Terminals
- Star Topology Yes
- RS-485 Yes
- Power DC
- Output Details 8 PNP/NPN, 2 Analog
- Feature: Hazardous Area No
- Point-to-Point Topology Yes
- RS-232 No
- Relative Humidity 95%
- Wireless Radio Frequency 900 MHz
- Input/Output Analog & Discrete
- Power Supply 12-30 V dc
- Modbus/TCP No
- Discrete Outputs Yes
- Environmental Rating (IP) IP20
- Tree Topology Yes
- Wireless Yes
- Analog Outputs Yes
- Max Temp Operating Conditions 60
- EtherNet/IP No
- Discrete Inputs Yes
- Point-to-Multipoint Topology Yes
- PROFINET No
- Input Details 2 Isolated Discrete, 8 Universal
- Application: Object Counting Yes
- 1-wire Serial Interface No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
DXM150-S2R2 Description
Banner Engineering DXM150-S2R2 is a remote I/O controller designed for DIN rail mounting and features a polycarbonate housing. It operates within an ambient air temperature range of -20 to +60°C and offers a degree of protection rated at IP20. This controller is equipped with 2 analog outputs (0-10Vdc), 2 digital outputs (SPDT / Form-C / NO/NC contact type; 16A / 250Vac), and 4 digital outputs (12Vdc-30Vdc; NMOS; 1A), alongside 2 digital inputs (12-30Vdc isolated inputs) and 8 digital inputs (12Vdc-30Vdc; Sink/Source/Counter) which can also function as 8AI (4-20mA / 0-10Vdc / 10kΩ thermistor). It supports Modbus I/O peripheral functionality within the DXM150-S2 series. Connection is facilitated via an RP-SMA connector, and it requires a supply voltage of 12-30Vdc (12Vdc-24Vdc nom.). Communication is enabled through RS-485 Modbus RTU, with a memory capacity of 2MB (on-board memory) and an expandable 8GB via SD card. The device operates on a 900MHz ISM band 1W radio (HE5 MultiHop data radio; North America), capable of a maximum 9.6km transmission distance at nominal emission power. Dimensions are H93.9mm x W156mm x D94.6mm.
Related documents DXM150-S2R2 Specs
