D10AFPQPMA20 Banner Electronic Components
Part#:D10AFPQPMA20
Manufacturer:Banner
Product Lifecycle:Active
Get a quick Quote!
Banner Engineering D10AFPQPMA20 is an amplifier designed for sensor applications, featuring a DIN rail mount for easy installation. This part has a net width of 11 mm and is constructed with a thermoplastic housing, a polycarbonate cover, and a polyurethane cable sheath, ensuring durability. It operates within an ambient air temperature range of -20 to +55 °C and offers a degree of protection rated at IP50 NEMA 1. The amplifier emits visible red light and has a response time of 500ms / 0.5 s. It includes 1 x digital output (NPN/PNP transistor) for connectivity. The rectangular shape and high-performance fiber optic sensor amplifier functionality are part of the D10 series. It features potentiometer adjustment for precise control and is pre-wired with a 6" / 150mm PUR cable terminated with a 4-pin Euro-style M12 connector for easy connection. The supply voltage requirement is 10Vdc-30Vdc (12Vdc / 24Vdc nom.), with net dimensions of 36 mm in depth and 69 mm in height.
About the manufacturer: Banner is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the D10AFPQPMA20 Banner price in the box on the right side or send a quick quote.
Product Details
- Main function Amplifier for sensor
- Sub-range name D10 series
- Primary brand Banner Engineering
- Display LED 4 digits display
- Light Color Visible red
- Response time 500ms / 0.5 s
- Order code / Manufacturer SKU 17621
- Net Width (mm) 10.5 mm
- Product series / family name Fiber optic amplifiers
- Supply voltage (DC) 10Vdc-30Vdc (12Vdc / 24Vdc nom.)
- Ambient air temperature for operation -20...+55 °C
- Technical compatibility with plastic fiber optic cable
- Net Depth (mm) 35.9 mm
- Shape Rectangular
- Mounting mode DIN rail mounting
- Degree of protection IP50 NEMA 1
- Compliant with standard(s) cURus CE
- Functions High-performance fiber optic sensor amplifier green LED (power ON) yellow LED (output state) potentiometer adjustment
- Material thermoplastic housing Polycarbonate cover PUR pigtail
- Net Height (mm) 68.1 mm
- Connection type Pre-wired with 6" / 150mm pigtail terminated with 4-pin Euro-style M12 connector
- Digital outputs 1 x digital output (NPN/PNP transistor)
- Contents mounting bracket M3 hardware
- Input/Output Discrete
- Cable Length (m) 0.15
- Power Supply/Supply Voltage 10-30 V dc
- Minimum response time (ms) .5
- Color LED - Amplifiers Red
- Max Op. Temperature (°C) 55
- Special Feature: Bussable Power No
- Housing Style DIN Rail
- NEMA Rating NEMA 1
- IO Link No
- Power DC
- Quick Disconnect Type M12 (Euro)
- Crosstalk Avoidance Yes
- Feature: Hazardous Area No
- Primary Housing Material Thermoplastic
- Connection Pigtail PUR QD
- Special Feature: Remote Teach No
- Feature: Timing (Hold/Delay) Yes
- Number of Pins 4
- Delay at Power-up (ms) 100
- Max Op. Relative Humidity (%) 90% @ 55°C
- Repeatability (µs) 95
- Output Type (Specific) Single Discrete
- Indicator Display Type Indicator LEDs
- Housing Material Thermoplastic
- Output Bipolar (NPN & PNP)
- IP Rating IP50
- Intrinsically Safe No
- Feature: Audible No
- Fiber Type Plastic and Glass
- Min Op. Temperature (°C) -20
- Adjustments Potentiometer
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents D10AFPQPMA20 Specs
