Supplementary Protectors

P1MB4PC63

P1MB4PC63 Lovato - Miniature circuit breaker, 4P - 10kA. 4 modules, characteristic C, 63A

Lovato Electric

FAZ-Z30/3N

Supplementary protector, 3 pole + neutral, 30 A, Z trip curve, 277/480 VAC, UL 1077

Eaton

2CCS862001R1325

ABB 2CCS862001R1325 is a Miniature Circuit Breaker (MCB) designed with screw-clamp connections. It features a rated current of 32A and a rated voltage of 500Vdc for DC applications. The device has a net height of 8 kV and a rated impulse voltage (Uimp) of 54 mm, indicating its capacity to withstand voltage spikes. With a net width for 2-poles (2P) configuration at 82.5 mm, it is suitable for DIN rail mounting. The MCB offers a protection function rated at 1000 V and a rated insulation voltage (Ui) of 82.5 mm. It is designed for 10,000 operations, indicating its mechanical endurance, and supports a control voltage type of AC. The supply voltage and analog outputs are also rated for 10,000 operations, with a secondary current specified as UC-B.

ABB Control

2CCS863001R1637

ABB 2CCS863001R1637 is a Miniature Circuit Breaker (MCB) designed for screw-clamp connections. It features a rated current of 100A and a rated voltage of 750Vdc. The device has a net height of 8 kV and a rated impulse voltage (Uimp) of 81 mm, with a net width accommodating 3-poles (3P). It offers protection functions at 1000 V and a rated insulation voltage (Ui) of 82.5 mm. This MCB is suitable for DIN rail mounting and is designed for 10,000 operations. It supports a control voltage (AC) and a supply voltage indicating durability for 10,000 operations, with secondary current specifications aligned with UC-K communication protocol.

ABB Control

3C05UR

Supplementary Protector 0.5A, 3 Pole, 480Y/277V AC, C Trip, UL1077

Altech Corp.

FAZ-Z16/3N

Supplementary protector, 3 pole + neutral, 16 A, Z trip curve, 277/480 VAC, UL 1077

Eaton

1100-SP1C2D10

Supplementary protector, 1 pole, 1 A, C trip curve, 277 VAC, UL 1077

c3controls

P1MB4PD02

P1MB4PD02 Lovato - Miniature circuit breaker, 4P - 10kA. 4 modules, characteristic D, 2A

Lovato Electric

S203MR-K30

MCB S200MR RTT 3P K 30A SUPP

ABB Control

2CCP842001R1329

ABB 2CCP842001R1329 is a Miniature Circuit Breaker (MCB) designed specifically for photovoltaic (PV) or solar DC applications. It features screw-clamp connections for secure installation and is rated for a current of 32A with a maximum DC voltage of 800Vdc. This MCB has a net height of 8 kV and a rated impulse voltage (Uimp) of 54 mm, indicating its robustness against voltage spikes. It is a 2-pole (2P) device, ensuring it can interrupt both poles simultaneously in the event of a fault. The net width is 82.5 mm, making it suitable for standard DIN rail mounting, a common installation method in electrical enclosures. Its protection functions are designed to handle up to 1500 V, with a rated insulation voltage (Ui) that supports efficient operation. The control voltage is AC, and it is built to withstand 10,000 operations, highlighting its durability and longevity in solar energy applications.

ABB Control

P1MBUH1PD08

P1MBUH1PD08 Lovato - Miniature circuit breaker, 1P - 10kA. 1 module, characteristic D, 8A

Lovato Electric

2CCS863001R0556

ABB 2CCS863001R0556 is a Miniature Circuit Breaker (MCB) designed with screw-clamp connections. It features a rated current of 40A and operates with a control voltage for DIN rail mounting. The MCB has a net height of 81 mm, a net width indicating a 3-pole (3P) configuration at 82.5 mm, and a rated impulse voltage (Uimp) of 8 kV. It is designed for a rated insulation voltage (Ui) of 690 V and supports a supply voltage up to 10,000 operations. The product is equipped to handle a secondary current and has an analog output also rated for 10,000 operations, emphasizing its capability for frequent use.

ABB Control

1100-SP1NB2D16

Supplementary protector, 1 pole + neutral, 1.6 A, B trip curve, 277 VAC, UL 1077

c3controls

2CCS884001R0251

ABB 2CCS884001R0251 is a Miniature Circuit Breaker (MCB) designed with screw-clamp connections. It features a rated current of 25A and a rated voltage of 500Vdc for DC applications. The MCB has a net height of 8 kV and a rated impulse voltage (Uimp) of 106 mm, indicating its capacity to withstand voltage spikes. It is equipped with 4 poles (4P) and has a net width of 82.5 mm. This model is designed for DIN rail mounting and has a rated insulation voltage (Ui) of 500 V. It supports a control voltage (AC) of 440 V and is rated for 10,000 operations. The MCB operates with a maximum temperature limit of 15 kA, ensuring its functionality under specified conditions.

ABB Control

1100-SP1NC2D20

Supplementary protector, 1 pole + neutral, 2 A, C trip curve, 277 VAC, UL 1077

c3controls

L8-32/2/B

Sprecher + Schuh L8-32/2/B - Supplementary Protectors, CURVE-B, 32A, 2-POLE, UL1077/ NFPA79/ CSA/ CE

Sprecher + Schuh

3DU13R

Supplementary Protector 13A, 3 Pole, 277V AC, D Trip, UL1077

Altech Corp.

FAZ-S7/1N

Supplementary protector, 1 pole + neutral, 7 A, S trip curve, 277/480 VAC, UL 1077

Eaton

3DU50R

Supplementary Protector 50A, 3 Pole, 277V AC, D Trip, UL1077

Altech Corp.

L8-63/1/D

Sprecher + Schuh L8-63/1/D - Supplementary Protectors, CURVE-D, 63A, 1-POLE, UL1077/ NFPA79/ CSA/ CE

Sprecher + Schuh
