175036WT3X5810-W60MV WEG AC Motors
Part#:175036WT3X5810-W60MV
Manufacturer:WEG
Product Lifecycle:Discontinued
Get a quick Quote!
W60 Hazardous Area 1750 HP 2P 6810/11 3Ph 2300/4000 V 60 Hz - Foot-mounted
Check out the 175036WT3X5810-W60MV WEG price in the box on the right side or send a quick quote.
Product Details
- Number of Poles 2
- Temperature rise 80 K
- Frame 6810/11
- No load current 85.0/48.9 A
- Mounting F-1
- Output rating 1750 HP
- Frequency 60 Hz
- Rated speed 3575 rpm
- Breakdown torque 229 %
- Duty Cycle Cont.(S1)
- Voltage 2300/4000 V
- L. R. Amperes 2370/1362 A
- Locked rotor time 18s (cold) 10s (hot)
- Service factor 1.00
- Ambient temperature 0°C to +40°C
- Number of poles 2
- Slip 0.69 %
- Locked rotor torque 50 %
- Standard NEMA MG-1
- Rated voltage 2300/4000 V
- Rotation¹ CW
- Output 1750 HP (1320 kW)
- Insulation Class F
- Altitude 1000 m.a.s.l.
- LRC 6.0x(Code F)
- Noise level² 88.0 dB(A)
- Terminal box¹ Left position
- Rated torque 2570 ft.lb
- Approx. weight³ 10666 lb
- Rated current 395/227 A
- Moment of inertia (J) 247 sq.ft.lb
- Starting Method VFD
- Synchronous speed 3600 rpm
- Degree of Protection IP24
- Flange Without
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents 175036WT3X5810-W60MV Specs
