12408340 WEG AC Motors
Part#:12408340
Manufacturer:WEG
Product Lifecycle:Discontinued
Get a quick Quote!
W21 Explosion-proof Motor NEMA Premium Efficiency 7.5 HP 4P 213TC 3Ph 575 V 60 Hz IC411 - TEFC - Foot-mounted
Check out the 12408340 WEG price in the box on the right side or send a quick quote.
Product Details
- Output 7.5 HP (5.5 kW)
- Insulation Class F
- Temperature rise 80 K
- Synchronous speed 1800 rpm
- Rated current 7.53 A
- Locked rotor torque 210 %
- Noise level² 58.0 dB(A)
- L. R. Amperes 50.4 A
- Locked rotor time 21s (cold) 12s (hot)
- Voltage 575 V
- Slip 1.94 %
- Rated torque 22.3 ft.lb
- Breakdown torque 280 %
- Duty Cycle Cont.(S1)
- Frame 213TC
- LRC 6.7x(Code H)
- Starting Method Direct On Line
- Standard NEMA MG-1
- Frequency 60 Hz
- Design B
- Enclosure IC411 - TEFC
- Output rating 7.5 HP
- No load current 2.72 A
- Ambient temperature -20°C to +40°C
- Mounting F-1
- Number of poles 4
- Rated speed 1765 rpm
- Rotation¹ Both (CW and CCW)
- Approx. weight³ 176 lb
- Rated voltage 575 V
- Service factor 1.15
- Degree of Protection IP55
- Terminal box¹ Left position
- Number of Poles 4
- Moment of inertia (J) 1.38 sq.ft.lb
- Altitude 1000 m.a.s.l.
- Flange C
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
