03009ET3Y250S/M-W22 WEG AC Motors
Part#:03009ET3Y250S/M-W22
Manufacturer:WEG
Alt. Part#:7909265039653
Product Lifecycle:Active
Get a quick Quote!
W22 Tru-Metric IE3 40 HP 8P 250S/M 3Ph 460//380-415 V 60 Hz IC411 - TEFC - B3L(E)
Check out the 03009ET3Y250S/M-W22 WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating40 HP
- Rated Speed730 rpm
- Number of Poles8 Pole
- Voltage380 V
- Flange TypeWithout
- L. R. Amperes 428 A
- LRC 7.4
- Duty Cycle S1
- Number of poles 8
- Flange Without
- Number of Poles 8
- Breakdown torque 250 %
- Ambient temperature -20°C to +40°C
- Voltage 460//380-415 V
- Rated current 57.9 A
- Moment of inertia (J) 33.9 sq.ft.lb
- Degree of Protection IP55
- Slip 2.67 %
- Design N
- Synchronous speed 900 rpm
- Locked rotor time 32s (cold) 18s (hot)
- Starting Method Direct On Line
- Noise level² 56.0 dB(A)
- Rated speed 730 rpm
- Temperature rise 80 K
- Mounting B3L(E)
- Standard NEMA MG-1
- Rated voltage 380 V
- Insulation Class F
- Altitude 1000 m.a.s.l.
- Terminal box¹ Right position
- Output 40 HP (30 kW)
- Rated torque 288 ft.lb
- Approx. weight³ 1145 lb
- Frame 250S/M
- Locked rotor torque 160 %
- Rotation¹ Both (CW and CCW)
- Frequency 50 Hz
- No load current 23.3 A
- Enclosure IC411 - TEFC
- Output rating 40 HP
