TTR875APSE4T-1.0FL-CTR Banner Safety Light Curtains

Banner TTR875APSE4T-1.0FL-CTR TTR Series 4 Beam Sensor Array 34.4 in Between Frame; Beam Spacing: 186.2 mm; Range: 120 mm Diffuse; Output: LO PNP; Input: 18-30 V dc; 1 m (3.3 ft) Flying Leads T: T-Slot Mount Endcap
Banner

Part#:TTR875APSE4T-1.0FL-CTR

Manufacturer:Banner

Alt. Part#:810271

Product Lifecycle:Active

Get a quick Quote!

TTR Series 4 Beam Sensor Array 34.4 in Between Frame; Beam Spacing: 186.2 mm; Range: 120 mm Diffuse; Output: LO PNP; Input: 18-30 V dc; 1 m (3.3 ft) Flying Leads T: T-Slot Mount Endcap

About the manufacturer: Banner is one of the manufacturers that offers Safety Light Curtains that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the TTR875APSE4T-1.0FL-CTR Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight430.9124 g
  • Country Of OriginMX
  • End Cap Type
    T: T-Slot Mounting
  • Adjustments
    N/A
  • NEMA Rating
    N/A
  • Cable Length (m)
    1
  • Indicator
    Indicator LEDs
  • Sensing Mode (Detailed)
    Diffuse
  • Power Supply/Supply Voltage
    18-30 V dc
  • Min Op. Temperature (°C)
    -10
  • Primary Housing Material
    Black Anodized Aluminum
  • Slot Overall Depth (mm)
    19
  • Operation
    Light/Dark Operate
  • Connection
    Cable
  • Lens Material
    Polycarbonate
  • Distance to First Beam [mm]
    158.2
  • Power
    DC
  • Quick Disconnect Type
    No QD
  • Delay at Power-up (ms)
    1500
  • Number of Beams
    4
  • Housing Style
    Roller Conveyor
  • Outputs
    PNP
  • Max Op. Temperature (°C)
    55
  • Slot Depth/Array Length (mm)
    869
  • Output response time (ms)
    1
  • IP Rating
    IP50
  • Max Sensing Range (mm)
    120
  • Number of Pins
    4
  • Max Op. Relative Humidity (%)
    95% @ 55°C
  • Beam to Beam Spacing [mm]
    186.2

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

TTR875APSE4T-1.0FL-CTR Description

Banner Engineering TTR875APSE4T-1.0FL-CTR is a sensor array designed with a diffuse mode featuring 4 beams. This part is pre-wired with a 1-meter cable that has bare end flying leads for connection. It has an array length of 875mm and operates on a supply voltage range of 18Vdc to 30Vdc, with a nominal voltage of 24Vdc. The ambient air temperature suitable for its operation ranges from -10 to +70 degrees Celsius. It offers a degree of protection rated at IP50 and comes in a rectangular shape. The distance between beams, or beam spacing/pitch, is 186.2mm. It includes 1 digital output (PNP transistor) and has a sensing distance of 120mm. The light color used for sensing is Infrared (IR) with a wavelength of 940 nm.

Related documents TTR875APSE4T-1.0FL-CTR Specs

TTR875APSE4T-1.0FL-CTR 216696.pdf
