T30R-1515-KDQ Banner Safety Light Curtains
Part#:T30R-1515-KDQ
Manufacturer:Banner
Alt. Part#:808907
Product Lifecycle:Active
Get a quick Quote!
T30R R-GAGE Series Radar Sensor; Range 15 m; Input: 10-30 V dc; Output: 1 PNP/NPN with IO-Link Communication; 1 PNP/NPN; 5-pin M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Safety Light Curtains that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the T30R-1515-KDQ Banner price in the box on the right side or send a quick quote.
Product Details
- Weight90.7184 g
- Country Of OriginUS
- Power DC
- Sensing Beam Radar
- PFM Output Yes
- Sensing Mode (Detailed) Time of Flight
- Operating Frequency 122 GHz
- Sensing Mode (General) Proximity
- Max Measurement Range >5 m - <=20 m
- Device Type Sensor
- Max Sensing Distance (mm) 15000
- Output Saturation Voltage PNP Outputs < 3 V at 50 mA
- Minimum Response Time (ms) 6
- Power/Current Consumption (exclusive of load) 100 mA max @ 24 V dc
- Profibus No
- Indicator LED(s)
- Power Supply 10-30 V dc
- Max Discrete (Switched) Output (mA) 50
- Remote Teach and Laser Control Input Impedence 55 kΩ
- Feature: Chemical Resistant No
- Wireless No
- Primary Housing Material PBT
- Delay at Power-up (ms) 300
- Output Protection Protected against short circuit
- Feature: Timing (Hold/Delay) Yes
- IO Link Yes
- Cert: European Yes
- Quick Disconnect Type M12 (Euro)
- Output Saturation Voltage NPN Outputs < 3 V at 50 mA
- Min Operating Temperature (°C) -40
- Feature: Remote Teach Yes
- RS-422 No
- Mechanical Shock MIL-STD-202G, Meth. 213B, conditions H&I (Shock: 75G with unit operation: 100G for non-operation).
- Barrel Diameter (mm) 30
- Feature: Clear Object Detection Yes
- Cert: US Yes
- Housing Style Barrel
- Minimum Sensing Distance (mm) 150
- IP Rating IP67
- Minimum Window Size (mm) 20
- RS-232 No
- SSI No
- PC Configurable Yes
- Connection Integral QD
- Number of Pins 5
- Max Operating Temperature (°C) 65
- Supply Protection Circuitry Protected against reverse polarity and transient overvoltages
- 1-wire Serial Interface No
- Input/Output Discrete
- Vibration MIL-STD-202F req. Method 201A (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).
- Max Op. Relative Humidity Non-Condensing (%) 95 at 50°C
- Discrete Output Hysteresis (mm) Manually settable from 50 to 15000 mm
- PROFINET No
- RS-485 No
- Radar Beam Pattern (H x V °) 15 x 15
- Adjustments Software; Push Button; Remote Teach
- Discrete (Switched) Outputs 2 NPN/PNP Configurable
- Max Off-state Leakage Current (µA) NPN: < 40 at 30 V dc; PNP: < 10 at 30 V dc
- Common Ethernet Protocol No
- Cert: Australia/New Zealand Yes
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
T30R-1515-KDQ Description
Banner Engineering T30R-1515-KDQ is a radar sensor belonging to the T30R series, designed with a time-of-flight system and approved for telecom use in the US, Europe, UK, Australia, and New Zealand. This retro-reflective radar sensor features a P.B.T. housing and is pre-equipped with a 5-pin Euro-style M12 connector. It operates on a supply voltage of 10Vdc-30Vdc, with nominal values of 12Vdc and 24Vdc. The sensor can function within an ambient air temperature range of -40 to +65°C and is protected by an IP67 degree of protection, making it suitable for harsh environments. Its M30 cylindrical threaded/barrel shape facilitates easy installation. The T30R-1515-KDQ offers two digital outputs (PNP/NPN transistor), supports a sensing distance of 0.15 to 15m, and includes protection functions against reverse polarity and short-circuit. The thread size for this sensor is M30.
