SP150GRYPQ Banner Signal Beacons
Part#:SP150GRYPQ
Manufacturer:Banner
Alt. Part#:11708
Product Lifecycle:Active
Get a quick Quote!
EZ-LIGHT Traffic Series: 1-Indicator, 3-Color Daylight Visible; Voltage: 15-30 V dc; Housing: Polycarbonate; IP67; Input: PNP; Colors: Green Yellow Red; M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the SP150GRYPQ Banner price in the box on the right side or send a quick quote.
Product Details
- Weight275.783936 g
- Country Of OriginUS
- Power DC
- Color Option 3 Yellow
- Max Input Response Time (ms) 10
- IO Link No
- Mounting Thread No Thread
- Lumens Color 2 7.0
- Lumens Color 3 6.0
- Feature: Hazardous Area No
- Multi-Color Device Single Color On
- Housing Style Flat Mount - Signal Light
- Color Option 1 Green
- Color Option 2 Red
- Number of Input Pins/Conductors 4
- Feature: Audible No
- Product Size (mm) Other
- Lumens Color 1 21.0
- Supply Voltage 15-30 V dc
- Feature: Chemical Resistant No
- Number of Colors / Segments 3
- Quick Disconnect Type M12 (Euro)
- Environmental Rating IP67
- Wireless No
- Indication Yes
- Connection Integral QD
- Max Current Color (mA) 40
- Min Op. Temperature (°C) -40
- Modbus RTU No
- Primary Housing Material Polycarbonate
- Animation Option 1 Solid On
- Color 3 - Wavelength/Color Temp/Coordinates 590 nm
- Max Op. Temperature (°C) 50
- Power Source DC
- Color Technology Standard LED
- Color 2 - Wavelength/Color Temp/Coordinates 625 nm
- Input Type PNP
- Application: Traffic Light Yes
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Color 1 - Wavelength/Color Temp/Coordinates 528 nm
- Physical Dimensions (LxWxH or DxH mm) 109.5 x 80.9 x 91.6
- Pro-Editor Compatible (Discrete) No
- Feature: Quick Disconnect Yes
- Indication Intensity High Brightness & Daylight Visible
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
SP150GRYPQ Description
Banner Engineering SP150GRYPQ is a traffic light from the EZ-LIGHT series designed with a 1-tier 3-color G/R/Y color pattern LED illumination. This LED traffic signal light features a polycarbonate (PC) base and is housed in black. It is pre-equipped with a 4-pin M12 Euro-style QD connector for connectivity. The SP150GRYPQ operates on a supply voltage of 15Vdc-30Vdc (24Vdc nom.) and can be mounted on surfaces or walls. It is designed to operate in ambient air temperatures ranging from -40°C to +50°C. With an IP67 degree of protection, it is safeguarded against dust and water ingress. The shape of the part is specifically designed to resemble a traffic light, and it has a current consumption of 40mA. Additionally, it features 3 x digital inputs (15-30Vdc; PNP) for color control.
Related documents SP150GRYPQ Specs
