SP150GRYP Banner Signal Beacons

Banner SP150GRYP EZ-LIGHT Traffic Series: 1-Indicator, 3 Color Daylight Visible; Voltage: 15-30 V dc; Housing: Polycarbonate; IP67; Input: PNP; Colors: Green Yellow Red; Field Wireable
Banner

Part#:SP150GRYP

Manufacturer:Banner

Alt. Part#:11691

Product Lifecycle:Active

Get a quick Quote!

EZ-LIGHT Traffic Series: 1-Indicator, 3 Color Daylight Visible; Voltage: 15-30 V dc; Housing: Polycarbonate; IP67; Input: PNP; Colors: Green Yellow Red; Field Wireable

About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the SP150GRYP Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight258.54744 g
  • Country Of OriginUS
  • Mounting Thread
    No Thread
  • Lumens Color 2
    20.0
  • Lumens Color 3
    6.0
  • Feature: Chemical Resistant
    No
  • Power Source
    DC
  • Color Option 1
    Green
  • Supply Voltage
    15-30 V dc
  • Max Op. Temperature (°C)
    50
  • Indication
    Yes
  • Lumens Color 1
    57.0
  • Color 3 - Wavelength/Color Temp/Coordinates
    590 nm
  • Indication Intensity
    High Brightness & Daylight Visible
  • Feature: Hazardous Area
    No
  • Primary Housing Material
    Polycarbonate
  • Connection
    Terminal
  • Max Input Response Time (ms)
    10
  • Number of Input Pins/Conductors
    4
  • Application: Traffic Light
    Yes
  • Power
    DC
  • Animation Option 1
    Solid On
  • Max Current Color (mA)
    40
  • Multi-Color Device
    Single Color On
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Color 1 - Wavelength/Color Temp/Coordinates
    528 nm
  • Physical Dimensions (LxWxH or DxH mm)
    93.1 x 80.9 x 91.6
  • IO Link
    No
  • Housing Style
    Flat Mount - Signal Light
  • Color Technology
    Standard LED
  • Input Type
    PNP
  • Min Op. Temperature (°C)
    -40
  • Modbus RTU
    No
  • Number of Colors / Segments
    3
  • Color 2 - Wavelength/Color Temp/Coordinates
    625 nm
  • Environmental Rating
    IP67
  • Pro-Editor Compatible (Discrete)
    No
  • Product Size (mm)
    Other
  • Color Option 2
    Red
  • Color Option 3
    Yellow
  • Feature: Audible
    No
  • Feature: Quick Disconnect
    No
  • Wireless
    No

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

SP150GRYP Description

Banner Engineering SP150GRYP, part of the EZ-LIGHT series, is a traffic light designed with a 1-tier 3-color G/R/Y color pattern LED illumination. This LED traffic signal light features a polycarbonate (PC) base and a black housing. It offers a screw-clamp terminal connection for secure installation. The SP150GRYP operates on a supply voltage of 15Vdc-30Vdc, with a nominal voltage of 24Vdc, and can be mounted on surfaces or walls. It is designed to function within an ambient air temperature range of -40°C to +50°C. With an IP67 degree of protection, this traffic light is safeguarded against dust and water ingress. It has a current consumption of 40mA and includes 3 x digital inputs (15-30Vdc; PNP) for color control.

Related documents SP150GRYP Specs

SP150GRYP 148879.pdf
