SP150GPQ Banner Signal Beacons
Part#:SP150GPQ
Manufacturer:Banner
Alt. Part#:11696
Product Lifecycle:Active
Get a quick Quote!
EZ-LIGHT Traffic Series: 1-Indicator Daylight Visible; Voltage: 15-30 V dc; Housing: Polycarbonate; IP67; Input: PNP/NPN Selectable; Colors: Green; M12 Integral QD
About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the SP150GPQ Banner price in the box on the right side or send a quick quote.
Product Details
- Weight280.319856 g
- Country Of OriginUS
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Power Source DC
- Primary Housing Material Polycarbonate
- Max Current Color (mA) 120
- Feature: Audible No
- Product Size (mm) Other
- Supply Voltage 15-30 V dc
- Indication Intensity High Brightness & Daylight Visible
- Pro-Editor Compatible (Discrete) No
- Power DC
- Lumens Color 1 57.0
- Number of Input Pins/Conductors 4
- Feature: Hazardous Area No
- Mounting Thread No Thread
- Animation Option 1 Solid On
- Physical Dimensions (LxWxH or DxH mm) 109.5 x 80.9 x 91.6
- Housing Style Flat Mount - Signal Light
- Color Technology Standard LED
- Max Op. Temperature (°C) 50
- IO Link No
- Number of Colors / Segments 1
- Color 1 - Wavelength/Color Temp/Coordinates 528 nm
- Feature: Chemical Resistant No
- Wireless No
- Indication Yes
- Quick Disconnect Type M12 (Euro)
- Environmental Rating IP67
- Feature: Quick Disconnect Yes
- Connection Integral QD
- Input Type Bimodal (PNP/NPN)
- Min Op. Temperature (°C) -40
- Color Option 1 Green
- Max Input Response Time (ms) 10
- Application: Traffic Light Yes
- Modbus RTU No
- Multi-Color Device Single Color On
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
SP150GPQ Description
Banner Engineering SP150GPQ, part of the EZ-LIGHT series, is a traffic light designed with a 1-tier 1-color green LED illumination. This automation part features a polycarbonate (PC) base and is housed in black. It is pre-equipped with a 4-pin M12 Euro-style QD connector for connectivity. The SP150GPQ operates on a supply voltage of 15Vdc-30Vdc, with 24Vdc nominal, and has a current consumption of 120mA. It offers a single digital input (15-30Vdc; PNP) for color control. Designed for surface or wall mounting, this traffic light operates within an ambient air temperature range of -40°C to +50°C and is rated with a degree of protection of IP67, indicating its suitability for various environmental conditions.
Related documents SP150GPQ Specs
1-year warranty
