SP150GP Banner Signal Beacons
Part#:SP150GP
Manufacturer:Banner
Alt. Part#:11686
Product Lifecycle:Active
Get a quick Quote!
EZ-LIGHT Traffic Series: 1-Indicator Daylight Visible; Voltage: 15-30 V dc; Housing: Polycarbonate; IP67; Input: PNP/NPN Selectable; Colors: Green; Field Wireable
About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the SP150GP Banner price in the box on the right side or send a quick quote.
Product Details
- Weight258.54744 g
- Country Of OriginUS
- Color Input Control Individual (One wire/color, same number of colors as input wires)
- Max Input Response Time (ms) 10
- Application: Traffic Light Yes
- Primary Housing Material Polycarbonate
- Lumens Color 1 57.0
- Max Op. Temperature (°C) 50
- IO Link No
- Power Source DC
- Color Option 1 Green
- Input Type Bimodal (PNP/NPN)
- Multi-Color Device Single Color On
- Number of Colors / Segments 1
- Color 1 - Wavelength/Color Temp/Coordinates 528 nm
- Environmental Rating IP67
- Modbus RTU No
- Indication Yes
- Animation Option 1 Solid On
- Feature: Hazardous Area No
- Pro-Editor Compatible (Discrete) No
- Housing Style Flat Mount - Signal Light
- Supply Voltage 15-30 V dc
- Min Op. Temperature (°C) -40
- Mounting Thread No Thread
- Connection Terminal
- Feature: Audible No
- Wireless No
- Physical Dimensions (LxWxH or DxH mm) 93.1 x 80.9 x 91.6
- Feature: Quick Disconnect No
- Power DC
- Color Technology Standard LED
- Number of Input Pins/Conductors 4
- Indication Intensity High Brightness & Daylight Visible
- Product Size (mm) Other
- Max Current Color (mA) 120
- Feature: Chemical Resistant No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
SP150GP Description
Banner Engineering SP150GP, part of the EZ-LIGHT series, is a traffic light designed with a 1-tier 1-color green LED illumination. This LED traffic signal light features a polycarbonate (PC) base and a black housing. It utilizes a screw-clamp terminal connection for secure installation. The SP150GP operates on a supply voltage of 15Vdc to 30Vdc, with a nominal voltage of 24Vdc, and can be mounted on surfaces or walls. It is designed to function within an ambient air temperature range of -40°C to +50°C. This product offers a degree of protection rated at IP67, ensuring its durability in various environmental conditions. It has a current consumption of 120mA and includes 1 x digital input (15-30Vdc; PNP) for color control.
Related documents SP150GP Specs
