FRV42436FT3G4479TDZ1 WEG AC Motors
Part#:FRV42436FT3G4479TDZ1
Manufacturer:WEG
Product Lifecycle:Discontinued
Get a quick Quote!
W40 NEMA Premium Efficiency 424 HP 2P 447/9TDZ 3Ph 460//380 V 60//50 Hz - Foot-mounted
Check out the FRV42436FT3G4479TDZ1 WEG price in the box on the right side or send a quick quote.
Product Details
- Rated voltage 460 V
- No load current 90.0 A
- Rated torque 624 ft.lb
- Degree of Protection IP23
- Duty Cycle Cont.(S1)
- Number of poles 2
- Rated current 457 A
- L. R. Amperes 3108 A
- Locked rotor torque 190 %
- Insulation Class H
- Frame 447/9TDZ
- Rated speed 3570 rpm
- Design A
- Breakdown torque 220 %
- Mounting F-1
- Locked rotor time 48s (cold) 27s (hot)
- Approx. weight³ 2591 lb
- Starting Method VFD
- Output rating 424 HP
- Slip 0.83 %
- Number of Poles 2
- Service factor 1.15
- Moment of inertia (J) 46.0 sq.ft.lb
- Rotation¹ CCW
- Temperature rise 105 K
- Noise level² 85.0 dB(A)
- Standard NEMA MG-1
- Synchronous speed 3600 rpm
- Terminal box¹ Left position
- Output 424 HP (312 kW)
- Frequency 60 Hz
- LRC 6.8x(Code G)
- Altitude 1000 m.a.s.l.
- Ambient temperature -20°C to +40°C
- Voltage 460//380 V
- Flange D
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents FRV42436FT3G4479TDZ1 Specs
1-year warranty
