17422663 WEG AC Motors
Part#:17422663
Manufacturer:WEG
Product Lifecycle:Discontinued
Get a quick Quote!
W60 Hazardous Area 300 HP 4P 5010/11 3Ph 2300/4000 V 60 Hz - Foot-mounted
Check out the 17422663 WEG price in the box on the right side or send a quick quote.
Product Details
- Slip 0.61 %
- Locked rotor torque 70 %
- Altitude 1000 m.a.s.l.
- Flange Without
- Frequency 60 Hz
- Moment of inertia (J) 178 sq.ft.lb
- Degree of Protection IP24
- Terminal box¹ Left position
- Frame 5010/11
- No load current 23.0/13.2 A
- Service factor 1.15
- Approx. weight³ 4630 lb
- L. R. Amperes 461/265 A
- Breakdown torque 225 %
- Noise level² 85.0 dB(A)
- Rated voltage 2300/4000 V
- Locked rotor time 36s (cold) 20s (hot)
- Mounting F-1
- Rated speed 1789 rpm
- Duty Cycle Cont.(S1)
- Voltage 2300/4000 V
- Output 300 HP (220 kW)
- Ambient temperature 0°C to +40°C
- Output rating 300 HP
- LRC 6.5x(Code G)
- Starting Method Direct On Line
- Number of poles 4
- Rated current 70.9/40.8 A
- Rated torque 881 ft.lb
- Temperature rise 80 K
- Standard NEMA MG-1
- Number of Poles 4
- Insulation Class F
- Rotation¹ Both (CW and CCW)
- Synchronous speed 1800 rpm
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
