13236ET3Y315S/M-W22 WEG AC Motors
Part#:13236ET3Y315S/M-W22
Manufacturer:WEG
Alt. Part#:7891327642706
Product Lifecycle:Active
Get a quick Quote!
W22 Tru-Metric IE3 175 HP 2P 315S/M 3Ph 460//380-415 V 60 Hz IC411 - TEFC - B3L(E)
Check out the 13236ET3Y315S/M-W22 WEG price in the box on the right side or send a quick quote.
Product Details
- Output Rating175 HP
- Rated Speed2977 rpm
- Number of Poles2 Pole
- Voltage380 V
- Flange TypeWithout
- LRC 7.0
- Altitude 1000 m.a.s.l.
- L. R. Amperes 1624 A
- Moment of inertia (J) 60.7 sq.ft.lb
- Flange Without
- Number of Poles 2
- Breakdown torque 250 %
- Ambient temperature -20°C to +40°C
- Noise level² 77.0 dB(A)
- Rated current 232 A
- No load current 48.0 A
- Enclosure IC411 - TEFC
- Voltage 460//380-415 V
- Output 175 HP (132 kW)
- Design N
- Starting Method Direct On Line
- Synchronous speed 3600 rpm
- Frequency 50 Hz
- Duty Cycle S1
- Standard NEMA MG-1
- Rated voltage 380 V
- Locked rotor time 113s (cold) 63s (hot)
- Degree of Protection IP55
- Output rating 175 HP
- Frame 315S/M
- Locked rotor torque 190 %
- Insulation Class F
- Rated speed 2977 rpm
- Temperature rise 80 K
- Mounting B3L(E)
- Number of poles 2
- Slip 0.77 %
- Rated torque 309 ft.lb
- Rotation¹ Both (CW and CCW)
- Terminal box¹ Right position
- Approx. weight³ 2497 lb
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
