1430213 Phoenix Contact Electrical Wires & Cables
Part#:1430213
Manufacturer:Phoenix Contact
Product Lifecycle:Active
Get a quick Quote!
Sensor/actuator cable, 17-position, PUR/PVC, black RAL 9005, shielded, Plug straight M12 SPEEDCON, coding: A, on free cable end, cable length: 3 m
About the manufacturer: Phoenix Contact is one of the manufacturers that offers Electrical Wires & Cables that you can order at marketplace.quotebeam.com. Phoenix Contact manufactures industrial electrical and electronic technology products that offer power, protection, connectivity, and automation for systems and equipment.
Check out the 1430213 Phoenix Contact price in the box on the right side or send a quick quote.
Product Details
- Ambient temperature (operation) -30 °C ... 80 °C (cable, fixed installation)
- Insulation resistance ≥ 10 MΩ*km (at 20 °C)
- Overvoltage category II
- Degree of protection IP65
- Status display No
- Degree of pollution 3
- Flame resistance According to DIN EN 60332-1-2
- Length of cable 3 m
- Rated current at 40°C 1.5 A
- Coding A - standard
- Flammability rating according to UL 94 V0
- Material of grip body TPU, hardly inflammable, self-extinguishing
- Other resistance hydrolysis and microbe resistant according to EN 50396
- Conductor structure signal line 18x 0.10 mm
- Optical shield covering 85 %
- Minimum bending radius, fixed installation 5 x D
- Cable weight 105 kg/km
- Test voltage, cable 1500 V AC
- ECLASS 4.1 27060300
- ECLASS 6.0 27279200
- ETIM 3.0 EC001855
- UNSPSC 12.01 31251501
- Traversing rate 3 m/s
- Outer sheath, material PUR
- Material, inner sheath PVC
- REACh SVHC Lead 7439-92-1
- ECLASS 5.1 27061800
- ETIM 4.0 EC001855
- UNSPSC 6.01 31251501
- UNSPSC 21.0 31251501
- Number of positions 17
- Protective circuit/component unwired
- Torque 0.4 Nm (M12 connector)
- Contact material CuZn
- Contact carrier material PA 6.6
- Cable type (abbreviation) 35T
- Cable abbreviation LSYWC11Y
- Wire colors White-brown, green-yellow, gray-pink, blue-red, black-violet, gray/pink-red/blue, white/green-brown/green, white/yellow-yellow/brown-white/gray
- External cable diameter D 9.2 mm ±0.2 mm
- Traversing path 10 m
- Acceleration 10 m/s²
- Conductor material Tin-plated Cu litz wires
- Nominal voltage, cable 42 V AC
- ECLASS 10.0.1 27060311
- ECLASS 7.0 27279218
- ETIM 7.0 EC001855
- UNSPSC 13.2 31251501
- Stripping length of the free conductor end 50 mm (Partial stripping)
- Rated voltage 30 V AC
- Standards/regulations M12 connector IEC 61076-2-101
- Resistance to oil in accordance with DIN EN 60811-2-1
- Contact surface material Ni/Au
- Material, knurls Zinc die-cast, nickel-plated
- UL AWM style 20233 / 1061 (80°C/300 V)
- Conductor cross section 17x 0.14 mm² (Signal line)
- Core diameter including insulation 1 mm ±0.05 mm (Signal line)
- External sheath, color black RAL 9005
- Number of bending cycles 4000000
- Bending radius 92 mm
- Conductor resistance 142 Ω/km (at 20 °C)
- China RoHS Environmentally Friendly Use Period = 50 years
- ECLASS 11.0 27060311
- ECLASS 5.0 27061800
- ETIM 6.0 EC001855
- UNSPSC 11 31251501
- UNSPSC 20.0 31251501
- Standards/specifications M12 connector IEC 61076-2-101
- Cable type Black PUR/PVC twisted pair
- AWG signal line 26
- Shielding Tinned copper braided shield
- Overall twist 7 pairs and 1 three-way unit, intertwisted
- Minimum bending radius, flexible installation 10 x D
- Material conductor insulation PVC
- Special properties Flexible cable conduit capable
- ECLASS 4.0 27060300
- ECLASS 9.0 27060311
- UNSPSC 7.0901 31251501
- UNSPSC 19.0 31251501
