P243C Mersen Fuse Holders
Part#:P243C
Manufacturer:Mersen
Alt. Part#:782001974176
Product Lifecycle:Active
Get a quick Quote!
P243C Mersen - Fuse Block 1000VAC 1000VDC 200A 1-Pole Stud center to center: 3.62 inch
About the manufacturer: Mersen is one of the manufacturers that offers Fuse Holders that you can order at marketplace.quotebeam.com. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the P243C Mersen price in the box on the right side or send a quick quote.
Product Details
- Number of Poles1 Pole
- Current Rating200 A
- Voltage1000 VAC
- Weight113.5 g
- Rated voltage AC UL 1000 V
- Torque Rating 36 lb-in
- Rated voltage DC UL 1000 V
- Installation Mounting Direct Screw Mount
- Frequency 50/60 Hz
- Fuse Type/Class Semiconductor
- Max Fuse Rating 200 A
- ROHS Compliant Yes
- Connection/Terminal Type Stud
- Number of Poles 1-pole
- Fuse Installation Method Bolt-in
- Ampere Rating 200 A
- Sell Pack Width 5 in
- Sell Pack Weight 1.31 lb
- Product Weight 0.25 lb
- Product Height 2.79 in
- Connection/Terminal Material Tin-Plated Copper
- Product Width 2.79 in
- Sell Pack Length 7.5 in
- Short Circuit Current Rating (SCCR) 10 kA
- Product Length 4.4 in
- Sell Pack Height 2.75 in
- Body/Insulating Material Phenolic
- Sell Pack Quantity 5 Each
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
P243C Description
P243C Mersen - Fuse Block 1000VAC 1000VDC 200A 1-Pole Stud center to center: 3.62 inch | Mersen P-Block series for Form 101 fuses are glass-filled polycarbonate or laminated phenolic insulator blocks with studs to accommodate bolt-in fuses. All studs, clips and mounting hardware are tin or zinc-plated | Features: *Glass-filled polycarbonate or laminated phenolic insulator blocks with
studs to accommodate bolt-in fuses | Application: *Fuse blocks for semiconductor fuses
