C088368 Mersen Fuses
Part#:C088368
Manufacturer:Mersen
Alt. Part#:3605340080476
Product Lifecycle:Active
Get a quick Quote!
C088368 Mersen - High-Speed Cylindrical Fuse Protistor® Size 20x127 gR (gRB) 1500VDC IEC 5A With Striker
About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at marketplace.quotebeam.com. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the C088368 Mersen price in the box on the right side or send a quick quote.
Product Details
- Current Rating5 A
- Trip ClassHigh Speed
- Fuse ClassSemiconductor
- Terminal TypeFerrule
- UL CertificationYES
- Weight97.156 g
- Country Of OriginFR
- Catalogue No. FD20GB150V5T
- Ampere Rating 5 A
- Max. Rated Breaking Capacity DC 30 kA
- Mounting Clip
- Fuse Size 20x127
- Speed/Characteristic gR
- Power Dissipation at Rated Current Value 2.3 W
- Rated voltage DC IEC 1500 V
- Design Details gRB
- Indication System Yes
- Connection/Terminal Material Silver-Plated Copper
- Indication System Type Striker
- Body/Insulating Material Ceramic
- Connection/Terminal Type Ferrule
- Product Diameter 0.81 in
- Product Weight 0.214 lb
- Product Length 5 in
- Sell Pack Width 5.51 in
- Sell Pack Quantity 10 EACH
- Sell Pack Height 1.18 in
- Sell Pack Weight 2.138 lb
- Sell Pack Length 10.63 in
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
C088368 Description
C088368 Mersen - High-Speed Cylindrical Fuse Protistor® Size 20x127 gR (gRB) 1500VDC IEC 5A With Striker
Product type: Semiconductor Protection Fuses
Specially developed for DC applications, 20x127 gR cylindrical is a fast acting, full range fuse used in the protection of auxiliaries, control circuit and other measuring and monitoring devices.
*International 20x127mm (13/16" x 5") for worldwide acceptance
*gR Class according to VDE 636-23 and IEC 60269-4
*Low I²t for improved semiconductor protection
*Eliminate all overloads
*Extremely fast acting
*Current limiting
*Excellent cycling capability
Related documents C088368 Specs
