A4BY5000-TI Mersen Fuses
Part#:A4BY5000-TI
Manufacturer:Mersen
Alt. Part#:782001939649
Product Lifecycle:Active
Get a quick Quote!
A4BY5000-TI Mersen - Fuse A4BY - Class L - Time-Delay 600VAC 300VDC 5000A Blade TI Indicator Amp-Trap®
About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at marketplace.quotebeam.com. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the A4BY5000-TI Mersen price in the box on the right side or send a quick quote.
Product Details
- Current Rating5000 A
- Voltage600 VAC / 300 VDC
- Trip ClassTime Delay
- TypeLow Voltage UL/CSA Fuses
- Fuse ClassClass L
- Terminal TypeBlade
- UL CertificationYES
- MaterialGMG
- Weight14285.25 g
- Approvals*Mersen Self-Certification, UL Listed to Standard 248-10, File E2137 *CSA Certified to Standard C22.2, No. 248.10 IEC 269-2-1 *DC Tested to UL 248 limits (Mersen Self-Certified)
- Rated voltage AC UL 600 V
- Rated voltage DC UL 300 V
- Indication System Yes
- Body/Insulating Material GMG
- ROHS Compliant Yes
- Fuse Class Class L
- Connection/Terminal Type Blade
- Product Diameter 6.25 in
- Sell Pack Weight 33.08 lb
- Ampere Rating 5000 A
- Mounting Bolted
- Connection/Terminal Material Silver-Plated Copper
- Sell Pack Quantity 1 Each
- Sell Pack Length 11.68 in
- Speed/Characteristic Time Delay
- AC Max I.R./Breaking Capacity: I1 200 kA
- Indication System Type TI Indicator
- Product Length 10.75 in
- Sell Pack Width 6.5 in
- Product Weight 31.5 lb
- Sell Pack Height 6.75 in
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
A4BY5000-TI Description
A4BY5000-TI Mersen - Fuse A4BY - Class L - Time-Delay 600VAC 300VDC 5000A Blade TI Indicator Amp-Trap®
Related documents A4BY5000-TI Specs
