A221260 Mersen Fuses
Part#:A221260
Manufacturer:Mersen
Alt. Part#:3605340251623
Product Lifecycle:Active
Get a quick Quote!
A221260 Mersen - British Standard fuse-link Protistor® 17x49 aR 690VAC IEC 63A With Striker
About the manufacturer: Mersen is one of the manufacturers that offers Fuses that you can order at marketplace.quotebeam.com. Mersen offers a diverse range of cooling products, bus bars, and custom fuses to efficiently control power electronics and safeguard them from damaging currents.
Check out the A221260 Mersen price in the box on the right side or send a quick quote.
Product Details
- Current Rating63 A
- Trip ClassHigh Speed
- Fuse ClassSemiconductor
- Weight49.94 g
- Country Of OriginFR,IN
- Fuse Size 17x49
- Rated voltage AC IEC 690 V
- Ampere Rating 63 A
- AC Max I.R./Breaking Capacity: I1 200 kA
- Mounting Bolted
- Speed/Characteristic aR
- Clearing I2t At Rated Voltage 1320 A²s
- Melting I2t 210 A²s
- Power Dissipation at Rated Current Value 19.5 W
- Catalogue No. BS17UZ69V63P
- Indication System Type Striker
- Body/Insulating Material Ceramic
- Indication System Yes
- Product Diameter 0.73 in
- Product Weight 0.11 lb
- Product Width 1.06 in
- Product Length 3.04 in
- Sell Pack Quantity 10 EACH
- Product Height 0.94 in
- Sell Pack Width 4.33 in
- Sell Pack Weight 1.102 lb
- Sell Pack Length 9.84 in
- Sell Pack Height 1.18 in
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
A221260 Description
A221260 Mersen - British Standard fuse-link Protistor® 17x49 aR 690VAC IEC 63A With Striker
Product type: Semiconductor Protection Fuses
The 690V Protistor® BS88-4 fuse-links provide maximum flexibility in equipment design and ultimate protection for protection of power semiconductors.These fuse-links are defined as per IEC 60269-1 and -4 , VDE 636-23 and BS88-4 for a worldwide acceptance.The Protistor® have been engineered to provide state-of-the-art protection for semiconductors: diodes, thyristors, GTO's and IGBT devices. Fuses are assembled with pure silver, die-cut elements embedded in solidified sand, which helps control arcing characteristics for a lower I²t and high interrupting rating level.
Each fuse-link can be equipped with a low voltage trip-indicator which can operate a field mountable microswitch.
*Extremely fast acting
*Current limiting
*Very high breaking capacity
*Low watts loss
