LM15675 Leeson Electronic Components
Part#:LM15675
Manufacturer:Leeson
Product Lifecycle:Active
Get a quick Quote!
General Purpose; 10HP; 256T Frame Size; 1200 Sync RPM; 230/460 Voltage; AC; TEFC Enclosure; NEMA Frame Profile; Three Phase; 60 Hertz; Rigid; Base; 1-5/8" Shaft Diameter; 6-1/4" Base to Center of Shaft; 25.15" Overall Length; 91 Efficiency Full Load
About the manufacturer: Leeson is one of the manufacturers that offers Electronic Components that you can order at marketplace.quotebeam.com. The LEESON® brand provides a diverse selection of AC and DC motors, gearmotors, and variable-speed control solutions tailored for demanding commercial and industrial environments. Whether you need a bulk order for OEM needs or single units for particular uses, LEESON® has the solution for you.
Check out the LM15675 Leeson price in the box on the right side or send a quick quote.
Product Details
- Horse Power 10HP
- Inch - Metric Inch
- Overall Length 25.15 Inch | 638.81 Millimeter
- Brand LEESON
- Base Yes
- Enclosure TEFC
- Base to Center Height - Millimeter 158.75
- UNSPSC 26101112
- Other Features Current Rating 26.2/13.1 Ampere | 6 Poles | General Purpose
- Voltage 230/460
- Current AC
- Sync RPM 1200
- Mounting Method Rigid
- Weight / LBS 294
- Frame Size 256T
- Base to Center of Shaft - Inch 6.25
- Minimum Buy Quantity N/A
- Frame Profile NEMA
- Weight / Kilogram 107.14
- Efficiency Full Load 91
- Hertz 60
- Phase Three Phase
- Shaft Diameter 1.625 Inch | 41.275 Millimeter
