8085183 Festo Pneumatic Actuators
Part#:8085183
Manufacturer:Festo
Alt. Part#:DGST-20-30-Y12A
Product Lifecycle:Active
Get a quick Quote!
mini slide DGST-20-30-Y12A Stroke: 30 mm, Adjustable endposition range/front length: 27 mm, Adjustable endposition range/rear length: 26,5 mm, Piston diameter: 20 mm, Operating mode of drive unit: Yoke
About the manufacturer: Festo is one of the manufacturers that offers Pneumatic Actuators that you can order at marketplace.quotebeam.com. Festo Corp. has been a top supplier of automation and intelligent automation solutions for more than four decades in the United States and eight decades globally. The company is committed to transforming the manufacturing sector and enhancing business efficiency.
Check out the 8085183 Festo price in the box on the right side or send a quick quote.
Product Details
- Guide Ball bearing cage guide
- Repetition accuracy <= 0.02 mm
- Ambient temperature -10 °C ... 60 °C
- Theoretical force at 6 bar, retracting 317 N
- Seals material HNBR
- Adjustable end-position range/front length 22.1 mm
- Drive unit operating mode Yoke
- Position sensing For proximity sensor
- Operating medium Compressed air as per ISO 8573-1:2010 [7:4:4]
- Max. force Fz 1110 N
- Max. torque My 12 Nm
- Product weight 1108 g
- Note on materials Free of copper and PTFE RoHS-compliant
- Housing material Wrought aluminum alloy
- Guide material POM High-alloy steel
- Piston diameter 20 mm
- Mounting position Any
- Operating pressure 0.1 MPa ... 0.8 MPa
- Mode of operation Double-acting
- Cushioning length 8 mm
- Max. torque Mz 12 Nm
- Type of mounting With through-hole
- Adjustable end-position range/rear length 22.1 mm
- Type code DGST
- Design Twin piston Slide
- Symbol 00991249
- Corrosion resistance class (CRC) 1 - Low corrosion stress
- Max. force Fy 1110 N
- Max. torque Mx 11 Nm
- Moving mass 512 g
- Cover material Wrought aluminum alloy
- Stroke 30 mm
- Cushioning External hydraulic cushioning
- Max. speed 0.8 m/s
- Information on operating and pilot media Operation with oil lubrication possible (required for further use)
- Impact energy in the end positions 3 J
- Theoretical force at 6 bar, advancing 377 N
- Pneumatic connection G1/8
- Piston rod material High-alloy stainless steel
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
Related documents 8085183 Specs
