JG3175A12S41 Eaton Industrial Automation Components
Part#:JG3175A12S41
Manufacturer:Eaton
Product Lifecycle:Active
Get a quick Quote!
JG3175A12S41 Eaton - Eaton Series C complete molded case circuit breaker, J-frame, Thermal-magnetic trip, Three-pole, 175A, 600 Vac, 14 kAIC at 480 Vac, Line/load, 2A-2B same side w/right pigtail, 12-24 Vac/dc same side w/ left pigtail, Reverse feed, 60 Hz
About the manufacturer: Eaton is one of the manufacturers that offers Industrial Automation Components that you can order at marketplace.quotebeam.com. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.
Check out the JG3175A12S41 Eaton price in the box on the right side or send a quick quote.
Product Details
- Product Name Eaton Series C complete molded case circuit breaker
- Shunt trip 12-24 Vac/dc same side with left pigtail shunt
- Auxiliary switch 2A-2B same side with right pigtail
- Class Engine Generator
- Product Height 7 in
- Catalog Number JG3175A12S41
- Frame J
- Voltage rating 600 Vac
- UPC 782116018796
- Number of poles Three-pole
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Circuit breaker frame type Complete breaker
- Certifications UL 489 IEC Rated UL Listed CSA Std. C22.2 No. 5 IEC 947-2 CSA Certified
- Functions Reverse
- Product Weight 9.21 lb
- Generator rating 63 kVA/51 kW at 240 Vac, 126 kVA/101 kW at 480 Vac, 158 kVA/126 kW at 600 Vac
- Interrupt rating 14 kAIC at 480 Vac
- Terminals Line and load
- Product Width 7 in
- Frequency rating 60 Hz
- Product Length/Depth 12 in
- Amperage Rating 175 A
- Trip Type Thermal-Magnetic
- Height 7 inches
- Length 12 inches
- Amperage 175 amperes
- Weight 9.21 pounds
- Terminal Type Line And Load
- Interrupt Rating 14 kiloamps
- Voltage 600 volts
