FG3030A12S03 Eaton Industrial Automation Components
Part#:FG3030A12S03
Manufacturer:Eaton
Product Lifecycle:Active
Get a quick Quote!
FG3030A12S03 Eaton - Eaton Series C complete molded case circuit breaker, F-frame, FG, Fixed thermal and magnetic trips, Three-pole, 30A, 600 Vac, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, 12-24 Vac/dc opposite side w/ left pigtail, Reverse, 60 Hz
About the manufacturer: Eaton is one of the manufacturers that offers Industrial Automation Components that you can order at marketplace.quotebeam.com. At Eaton, we are dedicated to improving quality of life and preserving the environment through power management technologies that emphasize reliability, efficiency, safety, and sustainability. Our attention is on impactful solutions, and we are committed to their success.
Check out the FG3030A12S03 Eaton price in the box on the right side or send a quick quote.
Product Details
- Trip Type Fixed Magnetic, Fixed Thermal
- Product Length/Depth 7.4 in
- Functions Reverse
- Product Width 5.1 in
- Amperage Rating 30 A
- Catalog Number FG3030A12S03
- Generator rating 11 kVA/9 kW at 240 Vac, 22 kVA/17 kW at 480 Vac, 27 kVA/22 kW at 600 Vac
- Product Weight 4.3 lb
- Number of poles Three-pole
- Auxiliary switch 2A-2B same side with right pigtail
- Product Name Eaton Series C complete molded case circuit breaker
- Pickup Fixed
- Terminals Line and load
- Certifications UL 489 IEC 947-2 CSA Std. C22.2 No. 5
- Frequency rating 60 Hz
- Product Height 6 in
- Warranty Eaton Selling Policy 25-000, one (1) year from the date of installation of the Product or eighteen (18) months from the date of shipment of the Product, whichever occurs first.
- Class Engine Generator
- Frame F
- UPC 786676013383
- Interrupt rating 14 kAIC at 480 Vac 18 kAIC at 240 Vac
- Circuit breaker frame type Complete breaker
- Shunt trip 12-24 Vac/dc left pigtail opposite
- Circuit breaker type FG
- Voltage rating 600 Vac
- Terminal Type Line And Load
- Voltage 600 volts
- Weight 4.3 pounds
- Height 6 inches
- Amperage 30 amperes
- Length 7.4 inches
- Interrupt Rating 14 kiloamps
