SP550BCLRGYYBQ Banner Signal Beacons

Banner SP550BCLRGYYBQ EZ-LIGHT Traffic Series: 5-Indicator K50 Beacon lights; Voltage: 15-30 V dc; Housing: Polycarbonate; IP65; Input: NPN; Colors: Red Green Yellow Yellow Blue, 8-pin M12 Integral
Banner

Part#:SP550BCLRGYYBQ

Manufacturer:Banner

Alt. Part#:18466

Product Lifecycle:Active

Get a quick Quote!

EZ-LIGHT Traffic Series: 5-Indicator K50 Beacon lights; Voltage: 15-30 V dc; Housing: Polycarbonate; IP65; Input: NPN; Colors: Red Green Yellow Yellow Blue, 8-pin M12 Integral

About the manufacturer: Banner is one of the manufacturers that offers Signal Beacons that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.

Check out the SP550BCLRGYYBQ Banner price in the box on the right side or send a quick quote.

Product Details

  • Weight2335.9988 g
  • Country Of OriginUS
  • Color Option 1
    Red
  • Number of Input Pins/Conductors
    8
  • Color Option 3
    Yellow
  • Feature: Chemical Resistant
    No
  • Power
    DC
  • Color Technology
    Standard LED
  • Lumens Color 3
    14.0
  • Max Op. Temperature (°C)
    50
  • Wireless
    No
  • Mounting Thread
    No Thread
  • Color Option 2
    Green
  • Color Option 5
    Blue
  • Physical Dimensions (LxWxH or DxH mm)
    210.0 x 80.0 x 105.2
  • Feature: Quick Disconnect
    Yes
  • Power Source
    DC
  • Lumens Color 2
    57.0
  • Lumens Color 5
    12.0
  • Min Op. Temperature (°C)
    -40
  • Modbus RTU
    No
  • Primary Housing Material
    Polycarbonate
  • Animation Option 1
    Solid On
  • Color 3 - Wavelength/Color Temp/Coordinates
    590 nm
  • Max Input Response Time (ms)
    10
  • IO Link
    No
  • Indication
    Yes
  • Color 1 - Wavelength/Color Temp/Coordinates
    625 nm
  • Color 4 - Wavelength/Color Temp/Coordinates
    590 nm
  • Environmental Rating
    IP65
  • Multi-Color Device
    Simultaneous Colors On
  • Housing Style
    Flat Mount - Signal Light
  • Quick Disconnect Type
    M12 (Euro)
  • Max Current Color (mA)
    120
  • Feature: Audible
    No
  • Color Input Control
    Individual (One wire/color, same number of colors as input wires)
  • Connection
    Integral QD
  • Lumens Color 4
    14.0
  • Input Type
    NPN
  • Application: Traffic Light
    Yes
  • Number of Colors / Segments
    5
  • Lumens Color 1
    20.0
  • Color Option 4
    Yellow
  • Supply Voltage
    15-30 V dc
  • Indication Intensity
    High Brightness & Daylight Visible
  • Product Size (mm)
    Other
  • Color 2 - Wavelength/Color Temp/Coordinates
    528 nm
  • Color 5 - Wavelength/Color Temp/Coordinates
    475 nm
  • Feature: Hazardous Area
    No
  • Pro-Editor Compatible (Discrete)
    No

Product condition

ORIGINAL PACKAGING

SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging

SP550BCLRGYYBQ Description

Banner Engineering SP550BCLRGYYBQ, part of the EZ-LIGHT series, is a traffic light designed with a 5-tiers 4-color R+G+Y+Y+B color pattern LED illumination. This LED traffic signal light features a polycarbonate (PC) base and is pre-equipped with an 8-pin M12 Euro-style QD connector for connectivity. The housing is gray, and it operates on a supply voltage of 15Vdc-30Vdc (24Vdc nom.). It can be mounted on surfaces or walls and is designed to operate in ambient air temperatures ranging from -40°C to +50°C. With an IP65 degree of protection, it is safeguarded against dust and low-pressure water jets from any direction. The shape is that of a traditional traffic light, and it has a current consumption of 120mA. Additionally, it includes 5 x digital inputs (15-30Vdc; NPN) for color control.

1-year warranty
