DEE8-41D Banner Cordsets
Part#:DEE8-41D
Manufacturer:Banner
Alt. Part#:10591
Product Lifecycle:Active
Get a quick Quote!
Cordset: Double Ended M12; 8-pin Straight Female; 4-pin Straight Male; 0.31 m 5x22 Yellow PVC Jacket; Nickel-Plated Brass Coupling Nuts
About the manufacturer: Banner is one of the manufacturers that offers Cordsets that you can order at marketplace.quotebeam.com. Banner Engineering Corp. is a globally renowned leader in the industrial automation sector. Our diverse product line, comprising sensors, vision sensors, LED lights, indicators, wireless devices, and safety products, caters to businesses of all sizes worldwide.
Check out the DEE8-41D Banner price in the box on the right side or send a quick quote.
Product Details
- Weight517.09488 g
- Country Of OriginTW
- Cordset Length (m) 0.31
- Primary Coupling Method M12 Single Key
- Cable Jacket Color Yellow
- Minimum Temp. (°C) -40
- Primary Number of Conductors 8
- Cable Jacket Material PVC
- Primary Connector Type EURO
- Secondary Connector Type EURO
- Coupling Material/Color Nickel Plated Brass
- Primary Orientation Straight
- Connector Body Material/Color PUR Black
- Current Rating (A) 2.0
- Shield/No Shield No Shield
- Voltage Rating (V) 60 V ac/75 V dc
- Secondary Number of Conductors 4
- Trunk Length (m) No Trunk
- IP Rating IP68
- Secondary AWG 22
- Number of Contacts 8
- Maximum Temp. (°C) 105
- Secondary Gender Male
- Outside Cable Diameter (mm) 6
- Primary Gender Female
- Feature: Hazardous Area No
- Number of Connectors 2
- Primary AWG 22
- Secondary Coupling Method M12 Single Key
- Secondary Orientation Straight
- Oil/Grease Resistant No
Product condition
ORIGINAL PACKAGING
SURPLUS ORIGINAL PACKAGING - 100% unused and in original packaging
DEE8-41D Description
Banner Engineering DEE8-41D is a pre-assembled, double-ended cable or cordset designed for various automation applications. It features an 8-pin Euro-style M12 female connector on one end and a 4-pin Euro-style M12 male connector on the other. The cable is made from PVC material and has a diameter of 6mm with a length of 31cm. It is encased in yellow sheathing. This part is engineered to operate within an ambient air temperature range of -40 to +105°C and offers a degree of protection rated at IP68. The DEE8-41D is rated for a voltage of 60Vac in AC applications and 75Vdc in DC applications.
